Xerox WorkCentre 5024 Service Manual

06/2014
6-35
WC 5022/5024
6.3.5 NVM DADF
General
Version 1.0
6.3.5 NVM DADF
Table 1 NVM DADF
Chain-Link NVM Name
Setting
Range
Default
Value step Description
711-001 DADF Lead Reg. Adjustment (Side 1) (220.0
mm/s)
105-135 120 0.1 mm 1) Default Value: 0 mm
(When 711-140 value is Default and 711-001 value is 120)
2) Adjustment Range (when 711-140 value is Default)
: +1.5 mm (105 pulse) / -1.5 mm (135 pulse)
3) Adjustment Range (when 711-140 value is 80 to 230)
: +5.5 mm (80 pulse) / -12.5 mm (230 pulse)
711-002 DADF Lead Reg. Adjustment (Side 1) (165.0
mm/s)
105-135 120 0.1 mm 1) Default Value: 0 mm
(When 711-140 value is Default and 711-002 value is 120)
2) Adjustment Range (when 711-140 value is Default)
: +1.5 mm (105 pulse) / -1.5 mm (135 pulse)
3) Adjustment Range (when 711-140 value is 80 to 230)
: +5.5 mm (80 pulse) / -12.5 mm (230 pulse)
711-003 DADF Lead Reg. Adjustment (Side 1) (110.0
mm/s)
105-135 120 0.1 mm 1) Default Value: 0 mm
(When 711-140 value is Default and 711-003 value is 120)
2) Adjustment Range (when 711-140 value is Default)
: +1.5 mm (105 pulse) / -1.5 mm (135 pulse)
3) Adjustment Range (when 711-140 value is 80 to 230)
: +5.5 mm (80 pulse) / -12.5 mm (230 pulse)
711-004 DADF Lead Reg. Adjustment (Side 1) (82.5 mm/
s)
105-135 120 0.1 mm 1) Default Value: 0 mm
(When 711-140 value is Default and 711-004 value is 120)
2) Adjustment Range (when 711-140 value is Default)
: +1.5 mm (105 pulse) / -1.5 mm (135 pulse)
3) Adjustment Range (when 711-140 value is 80 to 230)
: +5.5 mm (80 pulse) / -12.5 mm (230 pulse)
711-021 DADF Lead Reg. Adjustment (Side 2) (220.0
mm/s)
105-135 120 0.1 mm 1) Default Value: 0 mm
(When 711-141 value is Default and 711-021 value is 120)
2) Adjustment Range (when 711-141 value is Default)
: +1.5 mm (105 pulse) / -1.5 mm (135 pulse)
3) Adjustment Range (when 711-141 value is 80 to 230)
: +5.5 mm (80 pulse) / -12.5 mm (230 pulse)
711-022 DADF Lead Reg. Adjustment (Side 2) (165.0
mm/s)
105-135 120 0.1 mm 1) Default Value: 0 mm
(When 711-141 value is Default and 711-022 value is 120)
2) Adjustment Range (when 711-141 value is Default)
: +1.5 mm (105 pulse) / -1.5 mm (135 pulse)
3) Adjustment Range (when 711-141 value is 80 to 230)
: +5.5 mm (80 pulse) / -12.5 mm (230 pulse)
711-023 DADF Lead Reg. Adjustment (Side 2) (110.0
mm/s)
105-135 120 0.1 mm 1) Default Value: 0 mm
(When 711-141 value is Default and 711-023 value is 120)
2) Adjustment Range (when 711-141 value is Default)
: +1.5 mm (105 pulse) / -1.5 mm (135 pulse)
3) Adjustment Range (when 711-141 value is 80 to 230)
: +5.5 mm (80 pulse) / -12.5 mm (230 pulse)

Xerox WorkCentre 5024 Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	14 s
Print speed (black, normal quality, A3)	12 ppm
Print speed (black, normal quality, A4/US Letter)	24 ppm
Duplex print speed (black, normal quality, A4/US Letter)	17 ppm
Copy speed (black, normal quality, A3)	12 cpm
Copy speed (black, normal quality, A4)	24 cpm
Scan to	E-mail, PC
Scan drivers	TWAIN
Scanner type	ADF scanner
Scan speed (black)	22 ppm
Scan speed (color)	13 ppm
Faxing	-
Modem speed	33.6 Kbit/s
Printing colors	Black
Maximum duty cycle	25000 pages per month
Recommended duty cycle	0 - 25000 pages per month
Number of print cartridges	2
Wi-Fi	No
Email protocols	SMTP
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Internal memory	256 MB
Standard interfaces	USB 2.0
Display	LCD
Product color	Gray
Market positioning	Business
Windows operating systems supported	Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64
Paper input type	Paper tray
Total input capacity	350 sheets
Total output capacity	- sheets
Maximum input capacity	1850 sheets
Total number of input trays	5
Paper tray media types	Labels, Plain paper, Recycled paper
Paper tray media weight	60 - 90 g/m²
ISO A-series sizes (A0...A9)	A3, A4
ISO B-series sizes (B0...B9)	B4, B5
Maximum ISO A-series paper size	A3
Power consumption (average operating)	- W
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	574 mm
Width	594.3 mm
Height	581.6 mm
