Xerox WorkCentre 5024 Service Manual

06/2014
6-36
WC 5022/5024
6.3.5 NVM DADF
Version 1.0
General
711-024 DADF Lead Reg. Adjustment (Side 2) (82.5 mm/
s)
105-135 120 0.1 mm 1) Default Value: 0 mm
(When 711-141 value is Default and 711-024 value is 120)
2) Adjustment Range (when 711-141 value is Default)
: +1.5 mm (105 pulse) / -1.5 mm (135 pulse)
3) Adjustment Range (when 711-141 value is 80 to 230)
: +5.5 mm (80 pulse) / -12.5 mm (230 pulse)
711-041 DADF Tail Edge Adjustment (Side 1) (220.0 mm/
s)
0-255 151 0.0718 mm Default Value: 0 mm (151 pulse), +10.8 mm (-151 pulse) / -7.5 mm (+104 pulse)
Tail Edge adjustment = Lead Regi adjustment value + Tail Edge fine adjustment value
711-042 DADF Tail Edge Adjustment (Side 1) (165.0 mm/
s)
0-255 151 0.0718 mm Default Value: 0 mm (151 pulse), +10.8 mm (-151 pulse) / -7.5 mm (+104 pulse)
Tail Edge adjustment = Lead Regi adjustment value + Tail Edge fine adjustment value
711-043 DADF Tail Edge Adjustment (Side 1) (110.0 mm/
s)
0-255 151 0.0718 mm Default Value: 0 mm (151 pulse), +10.8 mm (-151 pulse) / -7.5 mm (+104 pulse)
Tail Edge adjustment = Lead Regi adjustment value + Tail Edge fine adjustment value
711-044 DADF Tail Edge Adjustment (Side 1) (82.5 mm/s) 0-255 151 0.0718 mm Default Value: 0 mm (151 pulse), +10.8 mm (-151 pulse) / -7.5 mm (+104 pulse)
Tail Edge adjustment = Lead Regi adjustment value + Tail Edge fine adjustment value
711-061 DADF Tail Edge Adjustment (Side 2) (220.0 mm/
s)
0-255 151 0.0718 mm Default Value: 0 mm (151 pulse), +10.8 mm (-151 pulse) / -7.5 mm (+104 pulse)
Tail Edge adjustment = Lead Regi adjustment value + Tail Edge fine adjustment value
711-062 DADF Tail Edge Adjustment (Side 2) (165.0 mm/
s)
0-255 151 0.0718 mm Default Value: 0 mm (151 pulse), +10.8 mm (-151 pulse) / -7.5 mm (+104 pulse)
Tail Edge adjustment = Lead Regi adjustment value + Tail Edge fine adjustment value
711-063 DADF Tail Edge Adjustment (Side 2) (110.0 mm/
s)
0-255 151 0.0718 mm Default Value: 0 mm (151 pulse), +10.8 mm (-151 pulse) / -7.5 mm (+104 pulse)
Tail Edge adjustment = Lead Regi adjustment value + Tail Edge fine adjustment value
711-064 DADF Tail Edge Adjustment (Side 2) (82.5 mm/s) 0-255 151 0.0718 mm Default Value: 0 mm (151 pulse), +10.8 mm (-151 pulse) / -7.5 mm (+104 pulse)
Tail Edge adjustment = Lead Regi adjustment value + Tail Edge fine adjustment value
711-081 Vertical Reduce/Enlarge Fine Adjustment 1
(High:TBD,Mid:220.0 mm/s, Low:TBD)
0-40 20 0.001 Default Value: 0% (20), +/-2% (+/-20), 0.1% increments
Adjusts only the Top Speed for Feed Motor.
711-082 Vertical Reduce/Enlarge Fine Adjustment 2
(High:TBD,Mid:165.0 mm/s, Low:TBD)
0-40 20 0.001 Default Value: 0% (20), +/-2% (+/-20), 0.1% increments
Adjusts only the Top Speed for Feed Motor.
711-083 Vertical Reduce/Enlarge Fine Adjustment 3
(High:TBD,Mid:110.0 mm/s, Low:TBD)
0-40 20 0.001 Default Value: 0% (20), +/-2% (+/-20), 0.1% increments
Adjusts only the Top Speed for Feed Motor.
711-084 Vertical Reduce/Enlarge Fine Adjustment 4
(High:TBD,Mid:82.5 mm/s, Low:TBD)
0-40 20 0.001 Default Value: 0% (20), +/-2% (+/-20), 0.1% increments
Adjusts only the Top Speed for Feed Motor.
711-140 DADF Lead Regi Offset NVM(Side 1) 80-230 120 0.1 mm Default Value: 0 mm (120 pulse), +4.0 mm (80 pulse) / -11.0 mm (230 pulse)
711-141 DADF Lead Regi Offset NVM(Side 2) 80-230 120 0.1 mm Default Value: 0 mm (120 pulse), +4.0 mm (80 pulse) / -11.0 mm (230 pulse)
711-142 DADF Tail Edge Replace All NVM (Side 1) 0-255 151 0.0718 mm
(x2 for Soft)
Default Value: 0 mm (151 pulse), +10.8 mm (-151 pulse) / -7.5 mm (+104 pulse)
Rewrites all data of 711-041 to 711-044 with the specified data.
711-143 DADF Tail Edge Replace All NVM (Side 2) 0-255 151 0.0718 mm
(x2 for Soft)
Default Value: 0 mm (151 pulse), +10.8 mm (-151 pulse) / -7.5 mm (+104 pulse)
Rewrites all data of 711-061 to 711-064 with the specified data.
711-144 Vertical Ratio Fine Adjustment - Replace All 0-40 20 0.001 Default Value: 0% (20), +/-2% (+/-20), 0.1% increments
Adjusts only the Top Speed for Feed Motor.
Rewrites all data of 711-081 to 711-084 with the specified data.
711-150 Loop Amount Adjustment (Side 1) (x1 Pulse) 0-9 6 40 Pulse Feed Roll Step: 0.026112
NVM 1Count: 0.026112 * 40 = 1.044 mm
711-151 Loop Amount Adjustment (Side 2) (x6 Pulse) 0-14 5 30 Pulse Exit Roll Step: 0.035904
NVM 1Count: 0.035904 * 30 = 1.077 mm
Table 1 NVM DADF
Chain-Link NVM Name
Setting
Range
Default
Value step Description

Xerox WorkCentre 5024 Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	14 s
Print speed (black, normal quality, A3)	12 ppm
Print speed (black, normal quality, A4/US Letter)	24 ppm
Duplex print speed (black, normal quality, A4/US Letter)	17 ppm
Copy speed (black, normal quality, A3)	12 cpm
Copy speed (black, normal quality, A4)	24 cpm
Scan to	E-mail, PC
Scan drivers	TWAIN
Scanner type	ADF scanner
Scan speed (black)	22 ppm
Scan speed (color)	13 ppm
Faxing	-
Modem speed	33.6 Kbit/s
Printing colors	Black
Maximum duty cycle	25000 pages per month
Recommended duty cycle	0 - 25000 pages per month
Number of print cartridges	2
Wi-Fi	No
Email protocols	SMTP
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Internal memory	256 MB
Standard interfaces	USB 2.0
Display	LCD
Product color	Gray
Market positioning	Business
Windows operating systems supported	Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64
Paper input type	Paper tray
Total input capacity	350 sheets
Total output capacity	- sheets
Maximum input capacity	1850 sheets
Total number of input trays	5
Paper tray media types	Labels, Plain paper, Recycled paper
Paper tray media weight	60 - 90 g/m²
ISO A-series sizes (A0...A9)	A3, A4
ISO B-series sizes (B0...B9)	B4, B5
Maximum ISO A-series paper size	A3
Power consumption (average operating)	- W
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	574 mm
Width	594.3 mm
Height	581.6 mm
