Xerox WorkCentre 5024 Service Manual

06/2014
6-38
WC 5022/5024
6.3.5 NVM DADF
Version 1.0
General
711-220 Usage of DPM Control Parameter Instructed
from the Controller
0-1 1 - 0: Cont DPM Parameter Reject
1: Cont DPM Parameter Accept
711-221 DADF DPM Control Parameter 0-255 101 - 100th Digit: Drive Type (0: High, 1: Middle, 2: Low)
10th Digit: Loop Control
1st Digit: Pre Regist Speed
711-272 Side 1 Side Regi Adjustment Value
(ADF-IIT Combine Adjustment Value Data 3)
0-240 120 - Side 1 Side Regi Adjustment Value
711-274 Side 2 Side Regi Adjustment Value
(ADF-IIT Combine Adjustment Value Data 5)
0-240 120 - Side 2 Side Regi Adjustment Value
711-276 ADF-IIT Combine Adjustment Value Data 7 0-255 0 - Adjustment Value Data 7 sent to IIT during ADF-IIT Combine
711-277 ADF-IIT Combine Adjustment Value Data 8 0-255 0 - Adjustment Value Data 8 sent to IIT during ADF-IIT Combine
711-278 ADF-IIT Combine Adjustment Value Data 9 0-255 0 - Adjustment Value Data 9 sent to IIT during ADF-IIT Combine
711-279 ADF-IIT Combine Adjustment Value Data 10 0-255 0 - Adjustment Value Data 10 sent to IIT during ADF-IIT Combine
711-280 ADF-IIT Combine Adjustment Value Data 11 0-255 0 - Adjustment Value Data 11 sent to IIT during ADF-IIT Combine
711-281 ADF-IIT Combine Adjustment Value Data 12 0-255 0 - Adjustment Value Data 12 sent to IIT during ADF-IIT Combine
711-282 ADF-IIT Combine Adjustment Value Data 13 0-255 0 - Adjustment Value Data 13 sent to IIT during ADF-IIT Combine
711-283 ADF-IIT Combine Adjustment Value Data 14 0-255 0 - Adjustment Value Data 14 sent to IIT during ADF-IIT Combine
711-284 ADF-IIT Combine Adjustment Value Data 15 0-255 0 - Adjustment Value Data 15 sent to IIT during ADF-IIT Combine
711-297 Communication Fail Bypass 0-1 0 - 0: Communication Fail Bypass OFF
1: Communication Fail Bypass ON
Table 1 NVM DADF
Chain-Link NVM Name
Setting
Range
Default
Value step Description

Xerox WorkCentre 5024 Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	14 s
Print speed (black, normal quality, A3)	12 ppm
Print speed (black, normal quality, A4/US Letter)	24 ppm
Duplex print speed (black, normal quality, A4/US Letter)	17 ppm
Copy speed (black, normal quality, A3)	12 cpm
Copy speed (black, normal quality, A4)	24 cpm
Scan to	E-mail, PC
Scan drivers	TWAIN
Scanner type	ADF scanner
Scan speed (black)	22 ppm
Scan speed (color)	13 ppm
Faxing	-
Modem speed	33.6 Kbit/s
Printing colors	Black
Maximum duty cycle	25000 pages per month
Recommended duty cycle	0 - 25000 pages per month
Number of print cartridges	2
Wi-Fi	No
Email protocols	SMTP
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Internal memory	256 MB
Standard interfaces	USB 2.0
Display	LCD
Product color	Gray
Market positioning	Business
Windows operating systems supported	Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64
Paper input type	Paper tray
Total input capacity	350 sheets
Total output capacity	- sheets
Maximum input capacity	1850 sheets
Total number of input trays	5
Paper tray media types	Labels, Plain paper, Recycled paper
Paper tray media weight	60 - 90 g/m²
ISO A-series sizes (A0...A9)	A3, A4
ISO B-series sizes (B0...B9)	B4, B5
Maximum ISO A-series paper size	A3
Power consumption (average operating)	- W
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	574 mm
Width	594.3 mm
Height	581.6 mm
