Page #467 background image
06/2014
6-39
WC 5022/5024
6.3.6.2 NVM IIT
General
Version 1.0
6.3.6.2 NVM IIT
Table 1 NVM IIT
Chain-Link NVM Name
Setting
Range
(Minimum
Value)
Setting
Range
(Maximum
Value)
Default
Value Read/Write Description
710-501Fax Document Size Detection 010OIndicates the switching of detection method when Fax Document Size Detection
is specified in DADF mode.
0: A/B series, 1: Inch series
710-551JAM Bypass 010O0: Do not bypass, 1: Bypass
Applies to CVT mode.
710-600Size Mismatch Set 133O1: When Size Mismatch is detected, notify a Jam.
2: Size Mismatch Detection OFF.
3: When Size Mismatch is detected, notify an operation fail and purge the docu-
ment. Reduced range for non-standard in the No Mixed Size Detection Table.
710-601Alternate Size Set 1 121OSwitches between 8.5x13 SEF and 8.46x12.4 SEF.
0: Default
1: 8.5x13 SEF
2: 8.46x12.4 SEF
710-602Alternate Size Set 2 121OSwitches between 8.5x14 SEF and 8.46x12.4 SEF.
0: Default
1: 8.5x14 SEF
2: 8.46x12.4 SEF
710-603Alternate Size Set 3 020OSwitches between 11x15 SEF and 11x17 SEF.
0: Default
1: 11x17 SEF
2: 11x15 SEF
710-604Alternate Size Set 4 020OSwitches between 8.5x13 SEF and 8.5x14 SEF.
0: Default
1: 8.5x13 SEF
2: 8.5x14 SEF or 8.5x13.4 SEF
710-605Alternate Size Set 5 020OB5 SEF
0: Default
1: B5 SEF
710-606Alternate Size Set 6 030OSwitches among 8x10 SEF, 8x10.5 SEF, and 8.5x11 SEF.
0: Default
1: 8.5x11 SEF
2: 8x10 SEF
3: 8x10.5 SEF
710-607Alternate Size Set 7 030OSwitches among 8x10 LEF, 8x10.5 LEF, and 8.5x11 LEF.
0: Default
1: 8.5x11 LEF
2: 8x10 LEF
3: 8x10.5 LEF
