06/2014
6-45
WC 5022/5024
6.3.6.2 NVM IIT
General
Version 1.0
715-3058.5x13/8.5x14 Detection 030O0: The default in the Table
1: For design verification, performance not guaranteed
2: 13 inch
3: 14 inch
715-306 Original detection table for special paper 020O0: Special documents not supported
1: A4 LEF when APS is OFF and A3 when APS in ON
2: Letter LEF when APS is OFF and 17 inch when APS in ON
715-307 Change Size Table 152O1: Inch 13-2
2: mm-2
3: mm
4: Inch 13-1
5: Inch 14
715-310A3/11x17 Detection 030O0: The default in the Table
1: A3 SEF
2: For design verification, performance not guaranteed
3: Detect as A3 SEF/11x17 SEF Mixed
715-311A4/8.5x11 Detection 030O0: The default in the Table
1: A4 LEF
2: For design verification, performance not guaranteed
3: Detect as 8.5x11 LEF/A4 LEF Mixed
715-312 A6 SEF Threshold 50 110 90 O Changes the Fast Scan direction threshold value for Non-standard, as well as
Japanese Postcard SEF, Postcard SEF, and A6 SEF. When other than 50 to 110
has been set, the Fast Scan direction threshold value is 90 mm.
50: 50 mm
[Down] (1 mm increment/step)
110: 110 mm
715-344Document Size Detection 030O(IISS)
0: Detection by 4 registers
1: Detection by 3 registers (countermeasure for dirt)
(IPoC)
0: Detection by 4 registers
1: Detection by 3 registers (countermeasure for dirt); 2 at open + the document
edge at close
2: Detection by 3 registers (countermeasure for dirt); 2 at open + the ladder
edge at close
3: Detection by 2 registers (countermeasure for dirt); 2 at open
715-346B4/8-Kai Detection 063O0: 256 mm 1: 258 mm 2: 260 mm 3: 262 mm
4: 264 mm 5: 266 mm 6: 268 mm
715-3478-Kai/11x17 Detection 063O0: 269 mm 1: 271 mm 2: 273 mm 3: 275 mm
4: 277 mm 5: 279 mm 6: 281 mm
715-349B6/5x7 Detection 020O0: The default in the Table
1: B6 SEF
2: 5x7 SEF
715-362 FL_CHK_NG_Count 0 65535 0 O Lamp Check NG Count (Reset when lamp is replaced)
Table 1 NVM IIT
Chain-Link NVM Name
Setting
Range
(Minimum
Value)
Setting
Range
(Maximum
Value)
Default
Value Read/Write Description
