Xerox WorkCentre 5024 Service Manual

06/2014
6-44
WC 5022/5024
6.3.6.2 NVM IIT
Version 1.0
General
715-113 CVT FS Side 4 Standard Adjustment 0 240 120 O Fast Scan Regi Reference Adjustment Value (0.1 mm/step) during CVT Side 4
"Factory Settings"
At Power ON, this will be overwritten by the DADF NVM (711-274) value.
715-280HOSEI_SCAN 063Ob* correction coefficient no., "Factory Settings"
715-281 LED_HOSEI_SCAN 0 19 5 O LED correction coefficient no., "Factory Settings"
Used for parameter selection at ENL
715-282 CCD Calib Y Scan Red 0 1023 O Red when scanning CCD Calib Y Patch (Reflective Ratio LSB)
"Factory Settings"
715-283 CCD Calib Y Scan Green 0 1023 0 O Red when scanning CCD Calib Y Patch (Reflective Ratio LSB)
"Factory Settings"
715-284 CCD Calib Y Scan Blue 0 1023 0 O Red when scanning CCD Calib Y Patch (Reflective Ratio LSB)
"Factory Settings"
715-285 CCD Calib M Scan Red 0 1023 0 O Red when scanning CCD Calib Y Patch (Reflective Ratio LSB)
"Factory Settings"
715-286 CCD Calib M Scan Green 0 1023 0 O Red when scanning CCD Calib Y Patch (Reflective Ratio LSB)
"Factory Settings"
715-287 CCD Calib M Scan Blue 0 1023 0 O Red when scanning CCD Calib Y Patch (Reflective Ratio LSB)
"Factory Settings"
715-288 CCD Calib C Scan Red 0 1023 0 O Red when scanning CCD Calib Y Patch (Reflective Ratio LSB)
"Factory Settings"
715-289 CCD Calib C Scan Green 0 1023 0 O Red when scanning CCD Calib Y Patch (Reflective Ratio LSB)
"Factory Settings"
715-290 CCD Calib C Scan Blue 0 1023 0 O Red when scanning CCD Calib Y Patch (Reflective Ratio LSB)
"Factory Settings"
715-291 CCD Calib PK Scan Red 0 1023 0 O Red when scanning CCD Calib Y Patch (Reflective Ratio LSB)
"Factory Settings"
715-292 CCD Calib PK Scan Green 0 1023 0 O Red when scanning CCD Calib Y Patch (Reflective Ratio LSB)
"Factory Settings"
715-293 CCD Calib PK Scan Blue 0 1023 0 O Red when scanning CCD Calib Y Patch (Reflective Ratio LSB)
"Factory Settings"
715-300A6 / Postcard Detection 020O0: The default in the Table
1: A6 SEF
2: Japanese Postcard SEF (mm series) or Postcard SEF (inch series)
715-302A4S/8.5in Detection 2 063O0: 210 mm 1: 211 mm 2: 212 mm 3: 213 mm
4: 214 mm 5: 215 mm 6: 216 mm
715-303B5/8x10 Detection 030O0: The default in the Table
1: Detect as B5 LEF or Executive LEF
2: Detect as 8x10 LEF/8x10.5 LEF Mixed
3: For design verification, performance not guaranteed
Table 1 NVM IIT
Chain-Link NVM Name
Setting
Range
(Minimum
Value)
Setting
Range
(Maximum
Value)
Default
Value Read/Write Description

Xerox WorkCentre 5024 Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	14 s
Print speed (black, normal quality, A3)	12 ppm
Print speed (black, normal quality, A4/US Letter)	24 ppm
Duplex print speed (black, normal quality, A4/US Letter)	17 ppm
Copy speed (black, normal quality, A3)	12 cpm
Copy speed (black, normal quality, A4)	24 cpm
Scan to	E-mail, PC
Scan drivers	TWAIN
Scanner type	ADF scanner
Scan speed (black)	22 ppm
Scan speed (color)	13 ppm
Faxing	-
Modem speed	33.6 Kbit/s
Printing colors	Black
Maximum duty cycle	25000 pages per month
Recommended duty cycle	0 - 25000 pages per month
Number of print cartridges	2
Wi-Fi	No
Email protocols	SMTP
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Internal memory	256 MB
Standard interfaces	USB 2.0
Display	LCD
Product color	Gray
Market positioning	Business
Windows operating systems supported	Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64
Paper input type	Paper tray
Total input capacity	350 sheets
Total output capacity	- sheets
Maximum input capacity	1850 sheets
Total number of input trays	5
Paper tray media types	Labels, Plain paper, Recycled paper
Paper tray media weight	60 - 90 g/m²
ISO A-series sizes (A0...A9)	A3, A4
ISO B-series sizes (B0...B9)	B4, B5
Maximum ISO A-series paper size	A3
Power consumption (average operating)	- W
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	574 mm
Width	594.3 mm
Height	581.6 mm
