Xerox WorkCentre 5024 Service Manual

06/2014
6-43
WC 5022/5024
6.3.6.2 NVM IIT
General
Version 1.0
715-083 CVT FS Offset Side 4-5 0 240 120 O Fast Scan Regi Correction Value (0.1 mm/step) during CVT
"Factory Settings"
715-084 CVT FS Offset Side 3-6 0 240 120 O Fast Scan Regi Correction Value (0.1 mm/step) during CVT
"Factory Settings"
715-085 CVT FS Offset Side 4-6 0 240 120 O Fast Scan Regi Correction Value (0.1 mm/step) during CVT
"Factory Settings"
715-086 CVT FS Offset Side 3-7 0 240 120 O Fast Scan Regi Correction Value (0.1 mm/step) during CVT
"Factory Settings"
715-087 CVT FS Offset Side 4-7 0 240 120 O Fast Scan Regi Correction Value (0.1 mm/step) during CVT
"Factory Settings"
715-088 CVT FS Offset Side 3-8 0 240 120 O Fast Scan Regi Correction Value (0.1 mm/step) during CVT
"Factory Settings"
715-089 CVT FS Offset Side 4-8 0 240 120 O Fast Scan Regi Correction Value (0.1 mm/step) during CVT
"Factory Settings"
715-090 CVT FS Offset Side 3-9 0 240 120 O Fast Scan Regi Correction Value (0.1 mm/step) during CVT
"Factory Settings"
715-091 CVT FS Offset Side 4-9 0 240 120 O Fast Scan Regi Correction Value (0.1 mm/step) during CVT
"Factory Settings"
715-092 WREF_ADJ__R 70 255 140 O Red W-Ref correction coefficient, "Factory Settings"
715-093 WREF_ADJ__G 70 255 140 O Green W-Ref correction coefficient, "Factory Settings"
715-094 WREF_ADJ__B 70 255 140 O Blue W-Ref correction coefficient, "Factory Settings"
715-095 WREF_ADJ__BWX 70 255 140 O BW-X W-Ref correction coefficient, "Factory Settings"
715-096 WREF_ADJ__BWY 70 255 140 O BW-Y W-Ref correction coefficient, "Factory Settings"
715-102 WREF_Offset_R 0 127 63 O Red W-Ref correction coefficient for each individual paper type.
715-103 WREF_Offset_G 0 127 63 O Green W-Ref correction coefficient for each individual paper type.
715-104 WREF_Offset_B 0 127 63 O Blue W-Ref correction coefficient for each individual paper type.
715-105 WREF_Offset_K 0 127 63 O BW W-Ref correction coefficient for each individual paper type.
715-106 IIT Paper Code 080O0: Use NVM Individual Paper Coefficient
1: J paper 2: P paper 3: C2 paper
4: Green100 paper 5: Digital Color Xpression
6: Color Tech+ 7: Xerox4200 paper
8: Xerox Business
715-110 CVT FS Side 1 Standard Adjustment 0 240 120 O Fast Scan Regi Reference Adjustment Value (0.1 mm/step) during CVT Side 1
"Factory Settings"
At Power ON, this will be overwritten by the DADF NVM (711-272) value.
715-111 CVT FS Side 2 Standard Adjustment 0 240 120 O Fast Scan Regi Reference Adjustment Value (0.1 mm/step) during CVT Side 2
"Factory Settings"
At Power ON, this will be overwritten by the DADF NVM (711-274) value.
715-112 CVT FS Side 3 Standard Adjustment 0 240 120 O Fast Scan Regi Reference Adjustment Value (0.1 mm/step) during CVT Side 3
"Factory Settings"
At Power ON, this will be overwritten by the DADF NVM (711-274) value.
Table 1 NVM IIT
Chain-Link NVM Name
Setting
Range
(Minimum
Value)
Setting
Range
(Maximum
Value)
Default
Value Read/Write Description

Xerox WorkCentre 5024 Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	14 s
Print speed (black, normal quality, A3)	12 ppm
Print speed (black, normal quality, A4/US Letter)	24 ppm
Duplex print speed (black, normal quality, A4/US Letter)	17 ppm
Copy speed (black, normal quality, A3)	12 cpm
Copy speed (black, normal quality, A4)	24 cpm
Scan to	E-mail, PC
Scan drivers	TWAIN
Scanner type	ADF scanner
Scan speed (black)	22 ppm
Scan speed (color)	13 ppm
Faxing	-
Modem speed	33.6 Kbit/s
Printing colors	Black
Maximum duty cycle	25000 pages per month
Recommended duty cycle	0 - 25000 pages per month
Number of print cartridges	2
Wi-Fi	No
Email protocols	SMTP
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Internal memory	256 MB
Standard interfaces	USB 2.0
Display	LCD
Product color	Gray
Market positioning	Business
Windows operating systems supported	Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64
Paper input type	Paper tray
Total input capacity	350 sheets
Total output capacity	- sheets
Maximum input capacity	1850 sheets
Total number of input trays	5
Paper tray media types	Labels, Plain paper, Recycled paper
Paper tray media weight	60 - 90 g/m²
ISO A-series sizes (A0...A9)	A3, A4
ISO B-series sizes (B0...B9)	B4, B5
Maximum ISO A-series paper size	A3
Power consumption (average operating)	- W
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	574 mm
Width	594.3 mm
Height	581.6 mm
