Page #470 background imageLoading...
Page #470 background image
06/2014
6-42
WC 5022/5024
6.3.6.2 NVM IIT
Version 1.0
General
715-062 CVT FS Offset Side 1-4 0 240 120 O Fast Scan Regi Correction Value (0.1 mm/step) during CVT
"Factory Settings"
715-063 CVT FS Offset Side 2-4 0 240 120 O Fast Scan Regi Correction Value (0.1 mm/step) during CVT
"Factory Settings"
715-064 CVT FS Offset Side 1-5 0 240 120 O Fast Scan Regi Correction Value (0.1 mm/step) during CVT
"Factory Settings"
715-065 CVT FS Offset Side 2-5 0 240 120 O Fast Scan Regi Correction Value (0.1 mm/step) during CVT
"Factory Settings"
715-066 CVT FS Offset Side 1-6 0 240 120 O Fast Scan Regi Correction Value (0.1 mm/step) during CVT
"Factory Settings"
715-067 CVT FS Offset Side 2-6 0 240 120 O Fast Scan Regi Correction Value (0.1 mm/step) during CVT
"Factory Settings"
715-068 CVT FS Offset Side 1-7 0 240 120 O Fast Scan Regi Correction Value (0.1 mm/step) during CVT
"Factory Settings"
715-069 CVT FS Offset Side 2-7 0 240 120 O Fast Scan Regi Correction Value (0.1 mm/step) during CVT
"Factory Settings"
715-070 CVT FS Offset Side 1-8 0 240 120 O Fast Scan Regi Correction Value (0.1 mm/step) during CVT
"Factory Settings"
715-071 CVT FS Offset Side 2-8 0 240 120 O Fast Scan Regi Correction Value (0.1 mm/step) during CVT
"Factory Settings"
715-072 CVT FS Offset Side 1-9 0 240 120 O Fast Scan Regi Correction Value (0.1 mm/step) during CVT
"Factory Settings"
715-073 CVT FS Offset Side 2-9 0 240 120 O Fast Scan Regi Correction Value (0.1 mm/step) during CVT
"Factory Settings"
715-074 CVT FS Offset Side 3-1 0 240 120 O Fast Scan Regi Correction Value (0.1 mm/step) during CVT
"Factory Settings"
715-075 CVT FS Offset Side 4-1 0 240 120 O Fast Scan Regi Correction Value (0.1 mm/step) during CVT
"Factory Settings"
715-076 CVT FS Offset Side 3-2 0 240 120 O Fast Scan Regi Correction Value (0.1 mm/step) during CVT
"Factory Settings"
715-077 CVT FS Offset Side 4-2 0 240 120 O Fast Scan Regi Correction Value (0.1 mm/step) during CVT
"Factory Settings"
715-078 CVT FS Offset Side 3-3 0 240 120 O Fast Scan Regi Correction Value (0.1 mm/step) during CVT
"Factory Settings"
715-079 CVT FS Offset Side 4-3 0 240 120 O Fast Scan Regi Correction Value (0.1 mm/step) during CVT
"Factory Settings"
715-080 CVT FS Offset Side 3-4 0 240 120 O Fast Scan Regi Correction Value (0.1 mm/step) during CVT
"Factory Settings"
715-081 CVT FS Offset Side 4-4 0 240 120 O Fast Scan Regi Correction Value (0.1 mm/step) during CVT
"Factory Settings"
715-082 CVT FS Offset Side 3-5 0 240 120 O Fast Scan Regi Correction Value (0.1 mm/step) during CVT
"Factory Settings"
Table 1 NVM IIT
Chain-Link NVM Name
Setting
Range
(Minimum
Value)
Setting
Range
(Maximum
Value)
Default
Value Read/Write Description
