06/2014
6-41
WC 5022/5024
6.3.6.2 NVM IIT
General
Version 1.0
715-018Config Fail Bypass 010OControls whether to perform Fail bypass for the [Configuration Check] function
of IIT-Elect Request.
Furthermore, this NVM is not involved with the separate SelectConfig that is
performed internally by the IISS.
0: Fail Bypass OFF
1: Fail Bypass ON
715-020Number Of APS Sensor 010O0: 1 APS
1: 2 APS
715-022Lamp Fan Fail Bypass 010OLamp Fan Fail Detection
0: Detects Lamp Fan Fail.
1: Does not detect Lamp Fan Fail.
715-026 Lamp On Interval 1 60 30 O Interval setting (Unit: min)
715-027 Lamp On Time 1 60 1 O Lamp ON time setting (Unit: s)
715-030 IIT Failure Part Diagnosis 0 65535 0 O Writing 1 starts the IIT Faulty Parts Diagnosis.
After that, the write value of this NVM will be changed from '1' to the presumed
faulty Parts No.
After the Faulty Part Diagnosis has completed, reading this NVM displays the
presumed faulty Part No.
When a Fail occurs during the Faulty Part Diagnosis, the Faulty Part Diagnosis
ends after the Fail code is recorded in this NVM.
* If other than '1' has been written, it will follow the usual NVM-Write operation.
(Faulty Parts Diagnosis will not be performed)
715-050 Platen SS Registration Adjustment 16 184 100 O Regi Correction in Slow Scan Direction
"Factory Settings"
715-051 Platen SS Magnification Adjustment 44 56 50 O Slow Scan Direction Regi Correction Value (0.1% increments)
"Factory Settings"
715-053 Platen PRadjF 0 240 120 O Fast Scan Regi Correction Value (Dot)
VLSS = PROMVLSS + (PRadjF -120) X 2
"Factory Settings"
715-056 CVT FS Offset Side 1-1 0 240 120 O Fast Scan Regi Correction Value (0.1 mm/step) during CVT
"Factory Settings"
715-057 CVT FS Offset Side 2-1 0 240 120 O Fast Scan Regi Correction Value (0.1 mm/step) during CVT
"Factory Settings"
715-058 CVT FS Offset Side 1-2 0 240 120 O Fast Scan Regi Correction Value (0.1 mm/step) during CVT
"Factory Settings"
715-059 CVT FS Offset Side 2-2 0 240 120 O Fast Scan Regi Correction Value (0.1 mm/step) during CVT
"Factory Settings"
715-060 CVT FS Offset Side 1-3 0 240 120 O Fast Scan Regi Correction Value (0.1 mm/step) during CVT
"Factory Settings"
715-061 CVT FS Offset Side 2-3 0 240 120 O Fast Scan Regi Correction Value (0.1 mm/step) during CVT
"Factory Settings"
Table 1 NVM IIT
Chain-Link NVM Name
Setting
Range
(Minimum
Value)
Setting
Range
(Maximum
Value)
Default
Value Read/Write Description
