Xerox WorkCentre 5024 Service Manual

06/2014
6-51
WC 5022/5024
6.3.9.2 NVM PH
General
Version 1.0
6.3.9.2 NVM PH
Table 1 NVM PH
Chain-Link NVM Name
Setting
Range
(Minimum
Value)
Setting
Range
(Maximum
Value)
Default
Value
Write Yes/
No
Initializatio
n Yes/NO Discription
742-001 PH_LEAD_REGI_ALL_TRAY -50 50 0 Disable Enable LEAD REGI ADJUSTMENT - ALL TRAY
Image input is delayed when Set Value is increased.
(Unit: 2 ms)
742-002 PH_LEAD_REGI_TRAY1 -50 50 0 Disable Enable TRAY1 for Normal LEAD REGI ADJ
Image input is delayed when Set Value is increased.
(Unit: 2 ms)
742-003 PH_LEAD_REGI_TRAY2 -50 50 0 Disable Enable TRAY2 for Normal LEAD REGI ADJ
Image input is delayed when Set Value is increased.
(Unit: 2 ms)
742-004 PH_LEAD_REGI_TRAY3 -50 50 0 Disable Enable TRAY3 for Normal LEAD REGI ADJ
Image input is delayed when Set Value is increased.
(Unit: 2 ms)
742-005 PH_LEAD_REGI_TRAY4 -50 50 0 Disable Enable TRAY4 for Normal LEAD REGI ADJ
Image input is delayed when Set Value is increased.
(Unit: 2 ms)
742-006 PH_LEAD_REGI_MSI -50 50 0 Disable Enable SMH for Normal LEAD REGI ADJ
Image input is delayed when Set Value is increased.
(Unit: 2 ms)
742-007 PH_LEAD_REGI_DUPLEX -50 50 0 Disable Enable DUP ALL SIZE for Normal LEAD REGI ADJ
Image input is delayed when Set Value is increased.
(Unit: 2 ms)
742-008 PH_LEAD_REGI_THICK1_TRAY1 -50 50 0 Disable Enable TRAY1 for thick1 LEAD REGI ADJ
Image input is delayed when Set Value is increased.
(Unit: 2 ms)
742-009 PH_LEAD_REGI_THICK1_TRAY2 -50 50 0 Disable Enable TRAY2 for thick1 LEAD REGI ADJ
Image input is delayed when Set Value is increased.
(Unit: 2 ms)
742-010 PH_LEAD_REGI_THICK1_TRAY3 -50 50 0 Disable Enable TRAY3 for thick1 LEAD REGI ADJ
Image input is delayed when Set Value is increased.
(Unit: 2 ms)
742-011 PH_LEAD_REGI_THICK1_TRAY4 -50 50 0 Disable Enable TRAY4 for thick1 LEAD REGI ADJ
Image input is delayed when Set Value is increased.
(Unit: 2 ms)
742-012 PH_LEAD_REGI_THICK1_MSI -50 50 0 Disable Enable SMH for thick1 LEAD REGI ADJ
Image input is delayed when Set Value is increased.
(Unit: 2 ms)
742-013 PH_LEAD_REGI_THICK1_DUPLEX -50 50 0 Disable Enable DUP ALL SIZE for thick1 LEAD REGI ADJ
Image input is delayed when Set Value is increased.
(Unit: 2 ms)

Xerox WorkCentre 5024 Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	14 s
Print speed (black, normal quality, A3)	12 ppm
Print speed (black, normal quality, A4/US Letter)	24 ppm
Duplex print speed (black, normal quality, A4/US Letter)	17 ppm
Copy speed (black, normal quality, A3)	12 cpm
Copy speed (black, normal quality, A4)	24 cpm
Scan to	E-mail, PC
Scan drivers	TWAIN
Scanner type	ADF scanner
Scan speed (black)	22 ppm
Scan speed (color)	13 ppm
Faxing	-
Modem speed	33.6 Kbit/s
Printing colors	Black
Maximum duty cycle	25000 pages per month
Recommended duty cycle	0 - 25000 pages per month
Number of print cartridges	2
Wi-Fi	No
Email protocols	SMTP
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Internal memory	256 MB
Standard interfaces	USB 2.0
Display	LCD
Product color	Gray
Market positioning	Business
Windows operating systems supported	Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64
Paper input type	Paper tray
Total input capacity	350 sheets
Total output capacity	- sheets
Maximum input capacity	1850 sheets
Total number of input trays	5
Paper tray media types	Labels, Plain paper, Recycled paper
Paper tray media weight	60 - 90 g/m²
ISO A-series sizes (A0...A9)	A3, A4
ISO B-series sizes (B0...B9)	B4, B5
Maximum ISO A-series paper size	A3
Power consumption (average operating)	- W
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	574 mm
Width	594.3 mm
Height	581.6 mm
