Xerox WorkCentre 5024 Service Manual

06/2014
6-52
WC 5022/5024
6.3.9.2 NVM PH
Version 1.0
General
742-014 PH_LEAD_REGI_THICK2_TRAY1 -50 50 0 Disable Enable TRAY1 for thick2 LEAD REGI ADJ
Image input is delayed when Set Value is increased.
(Unit: 2 ms)
742-015 PH_LEAD_REGI_THICK2_TRAY2 -50 50 0 Disable Enable TRAY2 for thick2 LEAD REGI ADJ
Image input is delayed when Set Value is increased.
(Unit: 2 ms)
742-016 PH_LEAD_REGI_THICK2_TRAY3 -50 50 0 Disable Enable TRAY3 for thick2 LEAD REGI ADJ
Image input is delayed when Set Value is increased.
(Unit: 2 ms)
742-017 PH_LEAD_REGI_THICK2_TRAY4 -50 50 0 Disable Enable TRAY4 for thick2 LEAD REGI ADJ
Image input is delayed when Set Value is increased.
(Unit: 2 ms)
742-018 PH_LEAD_REGI_THICK2_MSI -50 50 0 Disable Enable SMH for thick2 LEAD REGI ADJ
Image input is delayed when Set Value is increased.
(Unit: 2 ms)
742-019 PH_LEAD_REGI_THICK2_DUPLEX -50 50 0 Disable Enable DUP ALL SIZE for thick2 LEAD REGI ADJ
Image input is delayed when Set Value is increased.
(Unit: 2 ms)
742-020 PH_REGI_LOOP_ALL_TRAY -50 50 0 Disable Enable REGI LOOP ADJUSTMENT - ALL TRAY
Image input is delayed when Set Value is increased.
(Unit: 2 ms)
742-021 PH_REGI_LOOP_TRAY1 -50 50 0 Disable Enable TRAY1 for Normal REGI LOOP ADJ
Image input is delayed when Set Value is increased.
(Unit: 2 ms)
742-022 PH_REGI_LOOP_TRAY2 -50 50 0 Disable Enable TRAY2 for Normal REGI LOOP ADJ
Image input is delayed when Set Value is increased.
(Unit: 2 ms)
742-023 PH_REGI_LOOP_TRAY3 -50 50 0 Disable Enable TRAY3 for Normal REGI LOOP ADJ
Image input is delayed when Set Value is increased.
(Unit: 2 ms)
742-024 PH_REGI_LOOP_TRAY4 -50 50 0 Disable Enable TRAY4 for Normal REGI LOOP ADJ
Image input is delayed when Set Value is increased.
(Unit: 2 ms)
742-025 PH_REGI_LOOP_MSI -50 50 0 Disable Enable SMH for Normal REGI LOOP ADJ
Image input is delayed when Set Value is increased.
(Unit: 2 ms)
742-026 PH_REGI_LOOP_DUPLEX -50 50 0 Disable Enable DUP ALL SIZE for Normal REGI LOOP ADJ
Image input is delayed when Set Value is increased.
(Unit: 2 ms)
742-027 PH_REGI_LOOP_THICK1_TRAY1 -50 50 0 Disable Enable TRAY1 for thick1 REGI LOOP ADJ
Image input is delayed when Set Value is increased.
(Unit: 2 ms)
Table 1 NVM PH
Chain-Link NVM Name
Setting
Range
(Minimum
Value)
Setting
Range
(Maximum
Value)
Default
Value
Write Yes/
No
Initializatio
n Yes/NO Discription

Xerox WorkCentre 5024 Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	14 s
Print speed (black, normal quality, A3)	12 ppm
Print speed (black, normal quality, A4/US Letter)	24 ppm
Duplex print speed (black, normal quality, A4/US Letter)	17 ppm
Copy speed (black, normal quality, A3)	12 cpm
Copy speed (black, normal quality, A4)	24 cpm
Scan to	E-mail, PC
Scan drivers	TWAIN
Scanner type	ADF scanner
Scan speed (black)	22 ppm
Scan speed (color)	13 ppm
Faxing	-
Modem speed	33.6 Kbit/s
Printing colors	Black
Maximum duty cycle	25000 pages per month
Recommended duty cycle	0 - 25000 pages per month
Number of print cartridges	2
Wi-Fi	No
Email protocols	SMTP
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Internal memory	256 MB
Standard interfaces	USB 2.0
Display	LCD
Product color	Gray
Market positioning	Business
Windows operating systems supported	Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64
Paper input type	Paper tray
Total input capacity	350 sheets
Total output capacity	- sheets
Maximum input capacity	1850 sheets
Total number of input trays	5
Paper tray media types	Labels, Plain paper, Recycled paper
Paper tray media weight	60 - 90 g/m²
ISO A-series sizes (A0...A9)	A3, A4
ISO B-series sizes (B0...B9)	B4, B5
Maximum ISO A-series paper size	A3
Power consumption (average operating)	- W
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	574 mm
Width	594.3 mm
Height	581.6 mm
