YASKAWA MP2100 Series User Manual

6.5 Self-configuration
6-31
6
(a) Devices Recognized in Self-configuration
The devices that are recognized in self-configuration are listed below.
(b) Devices Not Recognized in Self-configuration
The devices that are not recognized in self-configuration are listed below.
Modules are detected as
∗∗∗∗
I/O. Reallocate as necessary.
Type Model Number Details
SERVO-
PACK
SGD-

N
SGDB-

AN
Σ
Series AC Servodrives
SGDH-

E
JUSP-NS100
Σ
-II Series SGDH Servodrives
Application Module
MECHATROLINK-I Interface Unit
SGDH-

E
JUSP-NS115
Σ
-II Series SGDH Servodrives
Application Module
MECHATROLINK-II Interface Unit
SGDS-

1
 Σ
-III Series AC Servodrives
Distributed
I/O Module
JAMSC-120DDI34330 DC Input Module
12/24 VDC, 16 inputs
JAMSC-120DDO34340 DC Output Module
12/24 VDC, 16 outputs
JAMSC-120AVI02030 A/D Module
Analog inputs,
−
10 to 10 V, 4 channels
JAMSC-120AVO01030 D/A Module
Analog outputs,
−
10 to 10 V, 2 channels
JAMSC-120EHC21140 Counter Module
Reversible counters, 2 channels
JAMSC-120MMB20230 Pulse Output Module
Pulse output, 2 channels
JEPMC-IO2310 64-point I/O Module
24 VDC, 64 inputs, 64 outputs
JEPMC-PL2900 Counter Module
Reversible counter, 2 channels
JEPMC-PL2910 Pulse Output Module
Pulse output, 2 channels
JEPMC-AN2900 A/D Module
Analog inputs,
−
10 to 10 V, 4 channels
JEPMC-AN2910 D/A Module
Analog outputs,
−
10 to 10 V, 2 channels
Type Model Number Details
Distributed
I/O Module
JEPMC-IO350
64-point I/O Module
24 VDC, 64 inputs, 64 outputs
JAMSC-120DAI53330
AC Input Module
100 VAC, 8 inputs
JAMSC-120DAI73330
AC Input Module
200 VAC, 8 inputs
JAMSC-120DAO83330
AC Output Module
100/200 VAC, 8 outputs
JAMSC-120DRA83030
Relay Module
Wide voltage range relay contacts,
8 contact inputs
