YASKAWA MP2100 Series User Manual

13.2 System Errors
13-15
13
(4) System Service Execution Status
Table 13.4 Ladder Program User Operation Error Status - 4
Error Code Error Contents User System Default
Integer -
Real
Number
Operations
1000H Index error within drawing
No
Re-executed with i, j = 0
2000H Index error within function
No
Re-executed with i, j = 0
Integer
Operation

060H
to

077H
(

= 1, 2)
Index error within integer system
function
No
Interrupt operation and output =
input
The A register remains the
same.
06DH
:
PI 06DH
:
PD 06FH
:
PID 070H
:
LAG
071H
:
LLAG 072H
:
FGN 073H
:
IFGN 074H
:
LAU
075H
:
SLAU 076H
:
FGN 077H
:
IFGN
Name Register No. Remarks
Reserved by System
SW00090
Reserved by System
SW00091
Reserved by System
SW00092
Reserved by System
SW00093
Reserved by System
SW00094
to
SW00097
Existence Of Data Trace
Definition
SW00098
Bit 0 to 3 = Group 1 to 4
Definition exists = 1, No definition = 0
Data Trace Execution Status
SW00099
Bit 0 to 3 = Group 1 to 4
Trace stopped = 1, Trace executing = 0
Table 13.5 Latest Data Trace Record Number
Name Register No. Remarks
Data Trace Group 1
SW00100
Latest record number
Data Trace Group 2
SW00101
Latest record number
Data Trace Group 3
SW00102
Latest record number
Data Trace Group 4
SW00103
Latest record number
