No.
(Addr.
Hex)
Name Description Values Page
F7-18
(3F6)
EtherNet/IP Current Scaling
Factor
Sets the scaling factor for the output current monitor in EtherNet/IP Class ID
2AH Object.
Default: 0
Min.: -15
Max.: 15
–
F7-19
(3F7)
EtherNet/IP Torque Scaling
Factor
Sets the scaling factor for the torque monitor in EtherNet/IP Class ID 2AH
Object.
Default: 0
Min.: -15
Max.: 15
–
F7-20
(3F8)
EtherNet/IP Power Scaling
Factor
Sets the scaling factor for the power monitor in EtherNet/IP Class ID 2AH
Object.
Default: 0
Min.: -15
Max.: 15
–
F7-21
(3F9)
EtherNet/IP Voltage Scaling
Factor
Sets the scaling factor for the voltage monitor in EtherNet/IP Class ID 2AH
Object.
Default: 0
Min.: -15
Max.: 15
–
F7-22
(3FA)
EtherNet/IP Time Scaling
Sets the scaling factor for the time monitor in EtherNet/IP Class ID 2AH
Object.
Default: 0
Min.: -15
Max.: 15
–
F7-23 to
F7-32
(3FB to
374)
Dynamic Output Assembly
Parameters
Parameters used in Output Assembly 116. Each parameter contains a
MEMOBUS/Modbus address. The value received for Output Assembly 116
will be written to this corresponding MEMOBUS/Modbus address. A
MEMOBUS/Modbus address value of 0 means that the value received for
Output Assembly 116 will not be written to any MEMOBUS/Modbus register.
Default: 0 –
F7-33 to
F7-42
(375 to
37E)
Dynamic Input Assembly
Parameters
Parameters used in Input Assembly 166. Each parameter contains a
MEMOBUS/Modbus address. The value sent for Input Assembly 166 will be
read from this corresponding MEMOBUS/Modbus address. A MEMOBUS/
Modbus address value of 0 means that the value sent for Input Assembly 166
is not defined by the user, therefore the option default register value will be
returned.
Default: 0 –
F7-60
(0780)
<1>
PZD1 Write
Sets MEMOBUS/Modbus address for PZD1 Write (PPO Write).
Values 0 to 2 enable the PZD1 Write as STW.
Default: 0
Min.: 0
Max.: FFFF
–
F7-61
(0781)
<1>
PZD2 Write
Sets MEMOBUS/Modbus address for PZD2 Write (PPO Write).
Values 0 to 2 enable the PZD2 Write as HSW.
Default: 0
Min.: 0
Max.: FFFF
–
F7-62
(0782)
<1>
PZD3 Write
Sets MEMOBUS/Modbus address for PZD3 Write (PPO Write).
Values 0 to 2 disable the PZD3 Write.
Default: 0
Min.: 0
Max.: FFFF
–
F7-63
(0783)
<1>
PZD4 Write
Sets MEMOBUS/Modbus address for PZD4 Write (PPO Write).
Values 0 to 2 disable the PZD4 Write.
Default: 0
Min.: 0
Max.: FFFF
–
F7-64
(0784)
<1>
PZD5 Write
Sets MEMOBUS/Modbus address for PZD5 Write (PPO Write).
Values 0 to 2 disable the PZD5 Write.
Default: 0
Min.: 0
Max.: FFFF
–
F7-65
(0785)
<1>
PZD6 Write
Sets MEMOBUS/Modbus address for PZD6 Write (PPO Write).
Values 0 to 2 disable the PZD6 Write.
Default: 0
Min.: 0
Max.: FFFF
–
F7-66
(0786)
<1>
PZD7 Write
Sets MEMOBUS/Modbus address for PZD7 Write (PPO Write).
Values 0 to 2 disable the PZD7 Write.
Default: 0
Min.: 0
Max.: FFFF
–
F7-67
(0787)
<1>
PZD8 Write
Sets MEMOBUS/Modbus address for PZD8 Write (PPO Write).
Values 0 to 2 disable the PZD8 Write.
Default: 0
Min.: 0
Max.: FFFF
–
F7-68
(0788)
<1>
PZD9 Write
Sets MEMOBUS/Modbus address for PZD9 Write (PPO Write).
Values 0 to 2 disable the PZD9 Write.
Default: 0
Min.: 0
Max.: FFFF
–
F7-69
(0789)
<1>
PZD10 Write
Sets MEMOBUS/Modbus address for PZD10 Write (PPO Write).
Values 0 to 2 disable the PZD10 Write.
Default: 0
Min.: 0
Max.: FFFF
–
F7-70
(078A)
<1>
PZD1 Read
Sets MEMOBUS/Modbus address for PZD1 Read (PPO Read).
Values 0 to 2 enable the PZD1 Read as ZSW.
Default: 0
Min.: 0
Max.: FFFF
–
F7-71
(078B)
<1>
PZD2 Read
Sets MEMOBUS/Modbus address for PZD2 Read (PPO Read).
Values 0 to 2 enable the PZD2 Read as HIW.
Default: 0
Min.: 0
Max.: FFFF
–
B.7 F: Communication Options
