Administrator’s Guide for SIP-T5 Series Smart Media Phones
460
Example of a NOTIFY message (<state>confirmed</state> shows the call has been established):
NOTIFY sip:1010@10.3.20.1:5060 SIP/2.0
Via: SIP/2.0/UDP 10.3.20.2:5060;branch=z9hG4bK276311022
From: <sip:1011@10.2.1.48:5060>;tag=3436332841
To: "1010" <sip:1010@10.2.1.48:5060>;tag=3098567568
Call-ID: 0_4117916748@10.3.20.1
CSeq: 4 NOTIFY
Contact: <sip:1011@10.3.20.2:5060>
Content-Type: application/dialog-info+xml
Max-Forwards: 70
User-Agent: Yealink T58 58.80.0.5
Subscription-State: active;expires=17
Event: dialog
Content-Length: 534
<?xml version="1.0"?>
<dialog-info xmlns="urn:ietf:params:xml:ns:dialog-info" version="3" state="partial"
entity="sip:1011@10.2.1.48:5060">
<dialog id="74" call-id="0_2561109579@10.3.20.1" local-tag="2778958897" remote-tag="1132018898"
direction="recipient">
<state>confirmed</state>
<local>
<identity>sip:1011@10.2.1.48:5060</identity>
<target uri="sip:1011@10.2.1.48:5060"/>
</local>
<remote>
<identity>sip:1010@10.2.1.48:5060</identity>
<target uri="sip:1010@10.2.1.48:5060"/>
</remote>
</dialog>
</dialog-info>
Visual Alert and Audio Alert for BLF Pickup
Visual and audio alert for BLF pickup allow the supervisor’s phone to play an alert tone and
display a visual prompt (e.g., “6001<-6002”, 6001 is the monitored extension which receives an
incoming call from 6002) when the monitored user receives an incoming call. In addition to the
BLF key, visual alert for BLF pickup feature enables the supervisor to pick up the monitored
user’s incoming call by tapping the Dpickup key. The directed call pickup code must be
configured in advance. For more information on how to configure the directed call pickup code
for the Dpickup key, refer to Directed Call Pickup on page 364.
BLF LED Mode
BLF LED Mode provides five kinds of definition for the BLF/BLF List key LED status. BLF LED
