Administrator’s Guide for SIP-T5 Series Smart Media Phones
416
To configure SIP send MAC feature via web user interface:
1. Click on Account->Advanced.
2. Select the desired account from the pull-down list of Account.
3. Select the desired value from the pull-down list of SIP Send MAC.
4. Click Confirm to accept the change.
SIP Send Line
The IP phone can send the line number in the REGISTER message. SIP send line allow adding
“Line:<linenumber>”(e.g., Line: 1) to the SIP header of the REGISTER message. The line number
is a number between 0 and 15.
The following table lists line number values for each phone model.
0~15 stand for line1~line16
Example of a SIP REGISTER message:
REGISTER sip:10.2.1.48:5060 SIP/2.0
Via: SIP/2.0/UDP 10.3.20.14:5060;branch=z9hG4bK3990593443
From: "11" <sip:11@10.2.1.48:5060>;tag=255071842
To: "11" <sip:11@10.2.1.48:5060>
