Yealink SIP-T58V/A User Manual

Administrator’s Guide for SIP-T5 Series Smart Media Phones
302
5. (Optional.) Enter the anonymous call on code and off code respectively in the On Code
and Off Code field beneath the Send Anony Code field.
6. Tap to accept the change.
Anonymous Call Rejection
Anonymous call rejection allows IP phones to automatically reject incoming calls from callers
whose identity has been deliberately concealed. The anonymous caller’s phone touch screen
presents “Anonymity Disallowed”. Anonymous call rejection is configurable on a per-line basis.
Example of anonymous call rejection SIP header:
SIP/2.0 433 Anonymity Disallowed
Via: SIP/2.0/UDP 10.10.20.32:5060;branch=z9hG4bK2816884590
From: "Anonymous" <sip:anonymous@anonymous.invalid>;tag=2625078618
To: <sip:1058@10.2.1.48:5060>;tag=2781829106
Call-ID: 4_510565349@10.10.20.32
CSeq: 1 INVITE
Allow: INVITE, INFO, PRACK, ACK, BYE, CANCEL, OPTIONS, NOTIFY, REGISTER, SUBSCRIBE, REFER, PUBLISH,
UPDATE, MESSAGE
User-Agent: Yealink T58 58.80.0.5
Allow-Events: talk, hold, conference, refer, check-sync
Content-Length: 0
The anonymous call rejection on code and anonymous call rejection off code configured on IP
phones are used to activate/deactivate the server-side anonymous call rejection feature. They
may vary on different servers. Send Anonymous Rejection Code feature allows IP phones to
send anonymous call rejection on/off code to the server.
Procedure
Anonymous call rejection can be configured using the following methods.
Central
Provisioning
(Configuration
File)
<MAC>.cfg
Configure anonymous call rejection.
Parameters:
account.X.reject_anonymous_call
account.X.send_anonymous_rejectio
n_code
account.X.anonymous_reject_oncod
e
account.X.anonymous_reject_offcod
e
Web User Interface
Configure anonymous call rejection.
Navigate to:
http://<phoneIPAddress>/servlet?m
