R Series Service Manual
1-32 9650-0903-01 Rev. L
18.0 SpO
2
Monitor Test (for SpO
2
Option)
Tools Needed:
• Masimo
Reusable Sensor.
• Masimo
Patient Cable.
• Fluke Biomedical Index 2XLFE SpO
2
Simulator (or equivalent).
Test Setup:
1. Connect the OneStep cable to the test port.
2. DO NOT connect the ECG cable to the simulator.
3. Install the Masimo
Patient Cable and attach the Masimo
sensor to the patient cable.
4. Connect the Masimo
sensor to the finger simulation post.
5. Place a fully charged battery into the battery well or connect to AC power.
6. Ensure that the SpO
2
Simulator is off.
Do this... Observe this... Pass/Fail
18.1 Turn the selector switch to MONITOR(for AED
units turn to ON, and select MANUAL MODE.)
The SpO
2
saturation percentage appears as a dashed line on the monitor.
oo
18.2 Wait ten seconds.
Turn on the SpO
2
simulator. Press the SIM
softkey on the Index SpO
2
Simulator. Press the
MAN softkey.
The SpO
2
PULSE SEARCH message displays.
oo
18.3 Press the 02+ or 02- softkey of the simulator
until the SpO
2
output is at 98%.
The R Series
SpO
2
reading of 98 +/- 1% appears on the R Series monitor.
Note that you may need to wait up to 2 minutes for the information to appear on
the ZOLL display.
oo
18.4
Using the Index
SpO
2
Simulator, press the
BPM+ or BPM- softkey until the heart rate is
230 BPM.
The SpO
2
rate 230 BPM displays on the simulator screen.
Note that you may need to wait up to 2 minutes for the information to appear on
the ZOLL display.
The
SpO
2
saturation of 96-100% appears on the R Series display.
The heart
rate of 226-234 BPM displays on the R Series monitor.
oo
To Next Page
