R Series Service Manual

1-34 9650-0903-01 Rev. L

19.0 EtCO

Monitor Test (for EtCO

Option)

Tools Needed: CAPNOSTAT 5 Mainstream cable with airway adapter.

Test Setup:

1. Install the battery.

Do this... Observe this... Pass/Fail

19.1 Connect the CAPNOSTAT 5 CO2 Mainstream

cable with airway adapter attached to the yellow

connector at the back of the R Series.

NOTE: Make sure the airway adapter is installed in the CO

cable.

19.2 Set the front panel switch to MONITOR or ON.

For AED units, enter Manual Mode.

WARM UP message appears on the display.

NOTE: Warming up may take up to 3 minutes.

19.3 When the WARM UP message disappears,

press the Param softkey, then select EtCO2.

19.4 Press the ZERO softkey, then wait for the

ZERO DONE message.

The ZERO DONE message appears.

19.5 Press the Return softkey.

19.6 Press the following softkeys to display the CO

waveform, Options, Traces, Trace 2, then

EtCO2,

A flat baseline CO

waveform appears.

19.7 Breathe normally into the airway adapter. A capnogram waveform appears.

Record your results on the Maintenance Test Checklist.
