R Series Service Manual
9650-0903-01 Rev. L 2-3
CF TRANSFER FAILED Summary/DVCK/ALOG data file transfer error – either no
CF card or CF card transfer failed
Reseat CF Communication cable or replace
Communication Module.
CHANGE LEADS Unit is in Defib Sync mode and heart rate is less than 20
BPM.
CHARGE FAILED Unit failed to perform the requested charge. Replace PD Engineer or Analog Board.
CHECK CO2 ADAPTER Airway adapter is removed, occluded or adapter zeroing
needs to be performed or was performed incorrectly.
Replace/Clean airway adapter. Zeroing performed
automatically.
CHECK CO2 SENSOR EtCO
2
Sensor is unplugged or defective.
Check that sensor cable is plugged in and seated
properly. Check that sensor is not exposed to
excessive heat. If problem persists, replace the
sensor.
CHECK CUFF/HOSE
• Blood pressure cuff or hose is not installed correctly.
• Cuff or hose is faulty.
• Hose is kinked or disconnected.
• Inflation rate too fast or too slow.
• Verify the hose and cuff is properly connected
and not leaking.
• Replace cuff and hose.
• Replace NIBP module or parameter power
supply.
CHECK ECG CABLE Invalid ECG cable Id is detected.
• Verify that the ECG Cable is property
connected.
• Replace ECG Cable.
• Replace Analog Board.
CHECK ELECTRODE Either Can read ID Chip or the checksum failed. Replace Electrodes or replace Analog board.
CHECK PADS Message displayed in conjunction with either POOR PAD
CONTACT or DEFIB PAD SHORT.
Ensure pads are coupled to patient. Check/
replace pads and universal cable. Replace system
board.
CHECK PATIENT Background ECG analysis detects shockable rhythm.
CHECK PULSE Alternate message for NO SHOCK ADV. message, or
displayed in addition to it according to the configuration
option selected. Also shown after delivering last shock
when Auto Analyze option is enabled.
Error Message Explanation User
Advisory
Technical Action
