Chapter 4 Installation and Debugging
Confidential and Proprietary Information of ZTE CORPORATION 21
FIGURE 9 INSTALLING FLANGES
3
2
1
2
3
1
1 Case 2 Flange 3 Screw
Install two symmetrical brackets at both sides of the 19-inch
cabinet to support the switch, as shown in
Figure 10.
