ZXR10 2920/2928/2952
(V1.0) Access Switch User Manual （Volume I）
22 Confidential and Proprietary Information of ZTE CORPORATION
FIGURE 10 INSTALLING BRACKETS
2
1
3
1 Holder 2 Cabinet 3 Screw
After installation, push switch along with bracket, and fix
flanges with screws onto cabinet, as shown in
Figure 11.
