1-11
Figure 1-10 Configuration progress dialog box
z After the configuration process is complete, click Close.
# Configure the ISP domain to use local authorization.
z Select Authentication > AAA from the navigation tree and then select the Authorization tab and
configure AAA authorization as shown in
Figure 1-11.
Figure 1-11 Configure the ISP domain to use local authorization
z Select the domain test.
z Select the Login AuthZ check box and select the authorization method Local.
z Click Apply. A configuration progress dialog box appears.
z After the configuration progress is complete, click Close.
# Configure the ISP domain to use local accounting.
z Select Authentication > AAA from the navigation tree and then select the Accounting tab and
configure AAA accounting as shown in
Figure 1-12.
