Def / Type
FbEq 16b / 32b
DescriptionName / Range /
Selection
No.
1 = 1 / 10 = 1Real signal value corresponding to maximum AO1 output
value.
-32768.0 ... 32767.0
0.000 mA / real32Defines the minimum output value for analog output AO1.
See also drawing at parameter 13.17 AO1 source min.
AO1 out at AO1 src
min
13.19
1000 = 1 mA / 1000 =
1 mA
Minimum AO1 output value.0.000 ... 22.000 mA
20.000 mA / real32Defines the maximum output value for analog output AO1.
See also drawing at parameter 13.17 AO1 source min.
AO1 out at AO1 src
max
13.20
1000 = 1 mA / 1000 =
1 mA
Maximum AO1 output value.0.000 ... 22.000 mA
- / real32Displays the value of AO2 in mA.
This parameter is read-only.
AO2 actual value13.21
1000 = 1 mA / 1000 =
1 mA
Value of AO2.0.000 ... 22.000 mA
Motor current / uint32Selects a signal to be connected to analog output AO2.
Alternatively, sets the output to excitation mode to feed a
constant current to a temperature sensor.
For the selections, see parameter 13.12 AO1 source.
AO2 source13.22
0.100 s / real32Defines the filtering time constant for analog output AO2.
See parameter 13.16 AO1 filter time.
AO2 filter time13.26
1000 = 1 s / 1000 = 1
s
Filter time constant.0.000 ... 30.000 s
