ABB ACS880 - Page 217

Def / Type
FbEq 16b / 32b
DescriptionName / Range /
Selection
No.
- / uint16
(Visible when 14.1 Module 1 type = FIO-11)
Shows the position of the hardware current/voltage selector
on the I/O extension module.
Note: The setting of the current/voltage selector must
match the unit selection made in parameter 14.60 AI3 unit
selection. I/O module reboot either by cycling the power
or through parameter 96.8 Control board boot is required
to validate any changes in the hardware settings.
AI3 HW switch
position
14.59
10Milliamperes.mA
2Volts.V
mA / uint16
(Visible when 14.1 Module 1 type = FIO-11)
Selects the unit for readings and settings related to analog
input AI3.
Note: This setting must match the corresponding hardware
setting on the I/O extension module (see the manual of the
I/O extension module). The hardware setting is shown by
parameter 14.59 AI3 HW switch position. I/O module reboot
either by cycling the power or through parameter 96.8
Control board boot is required to validate any changes in
the hardware settings.
AI3 unit selection14.60
10Milliamperes.mA
2Volts.V
1 ms / uint16
(Visible when 14.1 Module 1 type = FIO-11)
Selects a hardware filtering time for AI3.
See also parameter 14.62 AI3 filter time.
AI3 filter gain14.61
0No filtering.No filtering
1125 microseconds.125 us
2250 microseconds.250 us
3500 microseconds.500 us
41 millisecond.1 ms
52 milliseconds.2 ms
64 milliseconds.4 ms
77.9375 milliseconds.7.9375 ms
Parameters 217
