Def / Type
FbEq 16b / 32b
DescriptionName / Range /
Selection
No.
00Not selected
11Selected
2
Digital input DI1 (10.2 DI delayed status, bit 0).
DI1
3
Digital input DI2 (10.2 DI delayed status, bit 1).
DI2
4
Digital input DI3 (10.2 DI delayed status, bit 2).
DI3
5
Digital input DI4 (10.2 DI delayed status, bit 3).
DI4
6
Digital input DI5 (10.2 DI delayed status, bit 4).
DI5
7
Digital input DI6 (10.2 DI delayed status, bit 5).
DI6
10
Digital input/output DIO1 (11.2 DIO delayed status, bit 0).
DIO1
11
Digital input/output DIO2 (11.2 DIO delayed status, bit 1).
DIO2
Source selection See Terms and abbreviations (page 132).
Other [bit]
1.00 % / real32Adjusts the gain of the speed correction term in a
speed-controlled follower. In effect, defines how accurately
the follower follows the master torque. A greater value
results in a more accurate performance.
See section Load share function with a speed-controlled
follower (page 36).
Follower speed
correction gain
23.41
1 = 1 % / 100 = 1 %Speed correction term adjustment.0.00 ... 100.00 %
MF ref 2 / uint32Selects the source of the torque reference for the load
share function. See section Load share function with a
speed-controlled follower (page 36).
Follower speed corr
torq source
23.42
0None.NULL
1
3.14 M/F or D2D ref2 (page 143).
MF ref 2
See Terms and abbreviations (page 132).
Other
Parameters 277
