Def / Type
FbEq 16b / 32b
DescriptionName / Range /
Selection
No.
2
Digital input DI1 (10.2 DI delayed status, bit 0).
DI1
3
Digital input DI2 (10.2 DI delayed status, bit 1).
DI2
4
Digital input DI3 (10.2 DI delayed status, bit 2).
DI3
5
Digital input DI4 (10.2 DI delayed status, bit 3).
DI4
6
Digital input DI5 (10.2 DI delayed status, bit 4).
DI5
7
Digital input DI6 (10.2 DI delayed status, bit 5).
DI6
10
Digital input/output DIO1 (11.2 DIO delayed status, bit 0).
DIO1
11
Digital input/output DIO2 (11.2 DIO delayed status, bit 1).
DIO2
Source selection See Terms and abbreviations (page 132).
Other [bit]
No acknowledge /
uint32
Activates/deactivates (and selects the source for) brake
open/close status (acknowledgement) supervision.
When a brake control error (unexpected state of the
acknowledgement signal) is detected, the drive reacts as
defined by parameter 44.17 Brake fault function.
0 = Brake closed
1 = Brake open
Brake acknowledge
selection
44.7
00.Off
11.On
2Brake open/closed supervision disabled.No acknowledge
3
Digital input DI1 (10.2 DI delayed status, bit 0).
DI1
4
Digital input DI2 (10.2 DI delayed status, bit 1).
DI2
5
Digital input DI3 (10.2 DI delayed status, bit 2).
DI3
6
Digital input DI4 (10.2 DI delayed status, bit 3).
DI4
7
Digital input DI5 (10.2 DI delayed status, bit 4).
DI5
8
Digital input DI6 (10.2 DI delayed status, bit 5).
DI6
11
Digital input/output DIO1 (11.2 DIO delayed status, bit 0).
DIO1
12
Digital input/output DIO2 (11.2 DIO delayed status, bit 1).
DIO2
See Terms and abbreviations (page 132).
Other [bit]
0.00 s / real32Defines the brake open delay, ie. the delay between the
internal open brake command and the release of motor
speed control. The delay timer starts when the drive has
magnetized the motor and increased the motor torque to
the level required for brake release (parameter 44.3 Brake
open torque reference). Simultaneously with the timer start,
the brake control logic energizes the brake control output
and the brake starts to open.
Set this parameter to the value of mechanical opening
delay specified by the brake manufacturer.
Brake open delay44.8
100 = 1 s / 100 = 1 sBrake open delay.0.00 ... 5.00 s
396 Parameters
