Def / Type
FbEq 16b / 32b
DescriptionName / Range /
Selection
No.
Brake open torque /
uint32
Defines a source that is used as a brake opening torque
reference if
• its absolute value is greater than the setting of
parameter 44.10 Brake open torque, and
•
its sign is the same as the setting of 44.10 Brake open
torque.
See parameter 44.10 Brake open torque.
Brake open torque
source
44.9
0Zero.Zero
1
12.12 AI1 scaled value (page 189).
AI1 scaled
2
12.22 AI2 scaled value (page 191).
AI2 scaled
3
3.5 FB A reference 1 (page 142).
FBA ref1
4
3.6 FB A reference 2 (page 142).
FBA ref2
7
Parameter 44.2 Brake torque memory.
Brake torque memory
8
Parameter 44.10 Brake open torque.
Brake open torque
See Terms and abbreviations (page 132).
Other
0.0 % / real32Defines the sign (ie. direction of rotation) and minimum
absolute value of the brake open torque (motor torque
requested at brake release in percent of motor nominal
torque).
The value of the source selected by parameter 44.9 Brake
open torque source is used as the brake open torque only
if it has the same sign as this parameter and has a greater
absolute value.
Note: This parameter is not effective in scalar motor control
mode.
Brake open torque44.10
- / -Minimum torque at brake release. For scaling, see
parameter 46.3.
-1600.0 ... 1600.0 %
Not selected / uint32Selects a source that prevents the brake from opening.
0 = Normal brake operation
1 = Keep brake closed
Note: This parameter cannot be changed while the drive
is running.
Keep brake closed44.11
00Not selected
11Selected
2
Digital input DI1 (10.2 DI delayed status, bit 0).
DI1
3
Digital input DI2 (10.2 DI delayed status, bit 1).
DI2
4
Digital input DI3 (10.2 DI delayed status, bit 2).
DI3
5
Digital input DI4 (10.2 DI delayed status, bit 3).
DI4
6
Digital input DI5 (10.2 DI delayed status, bit 4).
DI5
7
Digital input DI6 (10.2 DI delayed status, bit 5).
DI6
10
Digital input/output DIO1 (11.2 DIO delayed status, bit 0).
DIO1
11
Digital input/output DIO2 (11.2 DIO delayed status, bit 1).
DIO2
