Def / Type
FbEq 16b / 32b
DescriptionName / Range /
Selection
No.
3
1.10 Motor torque is sent as actual value 1. The scaling is
defined by parameter 46.3 Torque scaling.
Torque
4
1.1 Motor speed used is sent as actual value 1. The scaling
is defined by parameter 46.1 Speed scaling.
Speed
5
1.6 Output frequency is sent as actual value 1. The scaling
is defined by parameter 46.2 Frequency scaling.
Frequency
6Motor position is sent as actual value 1. See parameter
90.6 Motor position scaled.
Position
Torque / uint16Selects the type/source and scaling of actual value 2
transmitted to the fieldbus network through the embedded
fieldbus interface.
EFB act2 type58.29
0Type/source and scaling follow the type of reference 2
selected by parameter 58.27 EFB ref2 type. See the
individual settings below for the sources and scalings.
Auto
1
The value selected by parameter 58.32 EFB act2
transparent source is sent as actual value 2. No scaling is
applied (the 16- bit scaling is 1 = 1 unit).
Transparent
2
The value selected by parameter 58.32 EFB act2
transparent source is sent as actual value 2 with a 16-bit
scaling of 100 = 1 unit (ie. integer and two decimals).
General
3
1.10 Motor torque is sent as actual value 2. The scaling is
defined by parameter 46.3 Torque scaling.
Torque
4
1.1 Motor speed used is sent as actual value 2. The scaling
is defined by parameter 46.1 Speed scaling.
Speed
5
1.6 Output frequency is sent as actual value 2. The scaling
is defined by parameter 46.2 Frequency scaling.
Frequency
6Motor position is sent as actual value 2. See parameter
90.6 Motor position scaled.
Position
Not selected / uint32
Selects the source of the status word when 58.25 Control
profile is set to Transparent.
EFB status word
transparent source
58.30
0None.Not selected
See Terms and abbreviations (page 132).
Other
Not selected / uint32
Selects the source of actual value 1 when 58.28 EFB act1
type is set to Transparent or General.
EFB act1 transparent
source
58.31
0None.Not selected
See Terms and abbreviations (page 132).
Other
Not selected / uint32
Selects the source of actual value 1 when 58.29 EFB act2
type is set to Transparent or General.
EFB act2 transparent
source
58.32
0None.Not selected
See Terms and abbreviations (page 132).
Other
Mode 0 / uint16Defines the mapping between parameters and holding
registers in the 400101…465535 Modbus register range.
Changes to this parameter take effect after the control unit
is rebooted or the new settings validated by parameter
58.6 Communication control.
Addressing mode58.33
Parameters 437
