ABB ACS880 - Page 455

Def / Type
FbEq 16b / 32b
DescriptionName / Range /
Selection
No.
0Type/source and scaling follow the type of reference 1
selected by parameter 60.60 DDCS controller ref1 type.
See the individual settings below for the sources and
scalings.
Auto
1Reserved.Transparent
2Reserved.General
3
1.10 Motor torque is sent as actual value 1. The scaling is
defined by parameter 46.3 Torque scaling.
Torque
4
1.1 Motor speed used is sent as actual value 1. The scaling
is defined by parameter 46.1 Speed scaling.
Speed
5
1.6 Output frequency is sent as actual value 1. The scaling
is defined by parameter 46.2 Frequency scaling.
Frequency
Auto / uint16Selects the type/source and scaling of actual value ACT2
transmitted to the external controller.
DDCS controller act2
type
60.63
0Type/source and scaling follow the type of reference 2
selected by parameter 60.61 DDCS controller ref2 type.
See the individual settings below for the sources and
scalings.
Auto
1Reserved.Transparent
2Reserved.General
3
1.10 Motor torque is sent as actual value 2. The scaling is
defined by parameter 46.3 Torque scaling.
Torque
4
1.1 Motor speed used is sent as actual value 2. The scaling
is defined by parameter 46.1 Speed scaling.
Speed
5
1.6 Output frequency is sent as actual value 2. The scaling
is defined by parameter 46.2 Frequency scaling.
Frequency
0 / uint16Selects the pair of data sets used by the mailbox service
in the drive/controller communication.
See section External controller interface (page 42).
Mailbox dataset
selection
60.64
1 = 1 / 1 = 1Data sets 32 and 33.0...1
- / uint16Activates DDCS controller communication monitoring
separately for each control location (see section Local
control vs. external control (page 23).
The parameter is primarily intended for monitoring the
communication with the controller when it is connected to
the application program and not selected as a control
source by drive parameters.
DDCS controller
comm supervision
force
60.65
1 = Communication monitoring active when Ext 1 is being
used.
Ext 1b0
1 = Communication monitoring active when Ext 2 is being
used.
Ext 2b1
1 = Communication monitoring active when local control
is being used.
Localb2
Reservedb3…15
1 = 10000h…FFFFh
Parameters 455
