ABB ACS880 - Page 511

Def / Type
FbEq 16b / 32b
DescriptionName / Range /
Selection
No.
- / uint16Shows the status of the user parameter sets.
Note: This parameter is read-only.
See also section User parameter sets (page 102).
User set status96.10
0No user parameter sets have been saved.n/a
1A user set is being loaded.Loading
2A user set is being saved.Saving
3Invalid parameter set.Faulted
4User set 1 has been loaded.User set 1
5User set 2 has been loaded.User set 2
6User set 3 has been loaded.User set 3
7User set 4 has been loaded.User set 4
No action / uint16Enables the saving and restoring of up to four custom sets
of parameter settings. See section User parameter
sets (page 102).
The set that was in use before powering down the drive is
in use after the next power-up.
Note: Hardware configuration settings such as I/O
extension module, fieldbus and encoder configuration
parameters (groups 14…16, 51…56, 58 and 92…93, and
parameters 50.1 and 50.31), and forced input/output values
(such as 10.3 and 10.4) are not included in user parameter
sets.
Note: Parameter changes made after loading a set are not
automatically stored – they must be saved using this
parameter.
Note: If no sets have been saved, attempting to load a set
will create all sets from the currently active parameter
settings.
Note: Switching between sets is only possible with the
drive stopped.
User set save/load96.11
0Load or save operation complete; normal operation.No action
1
Load user parameter set using parameters 96.12 and
96.13.
User set I/O mode
2Load user parameter set 1.Load set 1
3Load user parameter set 2.Load set 2
4Load user parameter set 3.Load set 3
5Load user parameter set 4.Load set 4
18Save user parameter set 1.Save to set 1
19Save user parameter set 2.Save to set 2
20Save user parameter set 3.Save to set 3
21Save user parameter set 4.Save to set 4
Parameters 511
