Terminal mode operation
105
1SVC 440 795 M1100
Terminal mode using the CL-NET topology
Figure: 75: Terminal mode in the CL-NET
In the above topology, the physical location is not identical
to the station number. The display system device was
connected in the middle of the network line. Terminal mode
functions irrespective of the device location and station
number.
1
1
2
5
3
7
4
3
R 1 - 12
S 1 - 6
R 1 - 12
S 1 - 8
