Display system operation
119
1SVC 440 795 M1100
Data block transfer function block,
error: range overlap
BT X E2 BT X E2 X=01…32 166
Data block transfer function block,
error: invalid offset
BT X E3 BT X E3 X=01…32 166
Boolean operation function block,
value zero
BV X ZE BV X ZE X=01…32 177
Counter function block, upper
setpoint value exceeded (Overflow)
C X OF c X OF X=01…32 180
Counter function block, lower
setpoint value undershot (Fall below)
C X FB c X FB X=01…32 180
Counter function block, actual value
equal to zero
C X ZE c X ZE X=01…32 180
Counter function block, actual value
has exceeded counter range (CARRY)
C X CY c X CY X=01…32 180
Frequency counter function block,
upper setpoint value exceeded
(Overflow)
CF X OF CF X OF X=01…04 187
Frequency counter function block,
lower setpoint value undershot
(Fall below)
CF X FB CF X FB X=01…04 187
Frequency counter function block,
actual value equal to zero
CF X ZE CF X ZE X=01…04 187
High-speed counter function block,
upper setpoint value exceeded
(Overflow)
CH X OF CH X OF X=01…04 191
High-speed counter function block,
lower setpoint value undershot
(Fall below)
CH X FB CH X FB X=01…04 191
High-speed counter function block,
actual value equal to zero
CH X ZE CH X ZE X=01…04 191
High-speed counter function block,
actual value has exceeded counter
range (CARRY)
CH X CY CH X CY X=01…04 191
Contact N/O contact N/C contact Number Page

ABB CL Series Specifications

General

Manufacturer	ABB
Rated Control Supply Voltage (Us)	24 V DC
Mounting	DIN Rail
Category	Relays
Contact Configuration	SPDT
Coil Voltage	24 V DC
Operating Temperature	-40°C to +70°C
Electrical Life	100 Thousand Cycles
Output	Relay
