ABB CL Series User Manual

Wiring with the display system
120
1SVC 440 795 M1100
Incremental encoder counter function
block, upper setpoint value exceeded
(Overflow)
CI X OF CI X OF X=01…02 196
Incremental encoder counter function
block, lower setpoint value undershot
(Fall below)
CI X FB CI X FB X=01…02 196
Incremental encoder counter function
block, actual value equal to zero
CI X ZE CI X ZE X=01…02 196
Incremental encoder counter function
block, actual value has exceeded
counter range (CARRY)
CI X CY CI X CY X=01…02 196
Comparator function block,
less than
CP X LT CP X LT X=01…32 201
Comparator function block,
equal to
CP X EQ CP X EQ X=01…32 201
Comparator function block,
Greater than
CP X GT CP X GT X=01…32 201
Data function block
DB X Q1 DB X Q1 X=01…32 203
PID controller, value range of
manipulated variable exceeded
DC X LI DC X LI X=01…32 205
Receive a variable from a station (Get) GT X Q1 GT X Q1 X=01…32 205
Seven-day time switch HW X Q1 HW X Q1 X=01…32 215
Year time switch function block HY X Q1 HY X Q1 X=01…32 220
Master reset, sets all outputs and
markers to zero state
MR X Q1 MR X Q1 X=01…32 231
Operating hours counter function
block, set time reached
OT X Q1 OT X Q1 X=01…04 237
Contact
N/O contact N/C contact Number Page

ABB CL Series Specifications

General

Manufacturer	ABB
Rated Control Supply Voltage (Us)	24 V DC
Mounting	DIN Rail
Category	Relays
Contact Configuration	SPDT
Coil Voltage	24 V DC
Operating Temperature	-40°C to +70°C
Electrical Life	100 Thousand Cycles
Output	Relay
