ABB CL Series User Manual

Display system operation
123
1SVC 440 795 M1100
Counter function block, set counter
value (Preset)
C X SE X=01…32 j j
Counter function block, reset counter
value
C X RE X=01…32 j j
Frequency counter function block,
activate counter (enable)
CF X EN X=01…04 j j
High-speed counter function block,
direction
CH X D_ X=01…04 j j
High-speed counter function block,
activate counter (enable)
CH X EN X=01…04 j j
High-speed counter function block,
set counter value (Preset)
CH X SE X=01…04 j j
High-speed counter function block,
reset counter value
CH X RE X=01…04 j j
Incremental encoder counter function
block, set counter value (Preset)
CI X SE X=01…02 j j
Incremental encoder counter function
block, activate counter (enable)
CI X EN X=01…02 j j
Incremental encoder counter function
block, reset counter value
CI X RE X=01…02 j j
Comparator function block CP X=01…32 – j
Activate text output function block
(enable)
D X EN X=01…32 j j
Data function block, trigger coil DB X T_ X=01…32 j j
PID controller, activate DC X EN X=01…32 j j
PID controller, activate P component DC X EP X=01…32 j j
PID controller, activate I component DC X EI X=01…32 j j
PID controller, activate D component DC X ED X=01…32 j j
PID controller, accept manual
manipulated variable
DC X SE X=01…32 j j
Activate signal smoothing filter FT X EN X=01…32 j j
Relay/function block
Display
system
display
Number Coil Parameter

ABB CL Series Specifications

General

Manufacturer	ABB
Rated Control Supply Voltage (Us)	24 V DC
Mounting	DIN Rail
Category	Relays
Contact Configuration	SPDT
Coil Voltage	24 V DC
Operating Temperature	-40°C to +70°C
Electrical Life	100 Thousand Cycles
Output	Relay
