Wiring with the display system
124
1SVC 440 795 M1100
You can set the switching behaviour of these relays by
means of the coil functions and parameters selected.
The options for setting output and marker relays are listed
with the description of each coil function.
Get from network station function
block
GT X=01…32 – j
Seven-day time switch HW X=01…32 – j
Year time switch function block HY X=01…32 – j
Activate value scaling function block LS X EN X=01…32 j j
Master reset function block MR X T_ X=01…32 j j
Activate numerical converter function
block
NC X EN X=01 32 j j
Function block operating hours
counter, enable
OT X EN X=01…04 j j
Operating hours counter function
block, reset
OT X RE X=01…04 j j
Send to the network (CL-NET)
function block, trigger
PT X T_ X=01…32 j j
Activate pulse width modulation
function block
PW X EN X=01…02 j j
Send time to the network (CL-NET)
function block, trigger
SC X T_ X=01 j –
Activate set cycle time function block ST X EN X=01
Timing relay function block, trigger
control coil (enable)
T X EN X=01…32 j j
Timing relay function block, stop T X ST X=01…32 j j
Timing relay function block, reset T X RE X=01…32 j j
Activate value limitation function
block
VC X EN X=01…32 j j
Relay/function block Display
system
display
Number Coil Parameter
