ABB CL Series User Manual

Function blocks
207
1SVC 440 795 M1100
Actual value …QV>
The actual value …QV> can be assigned the following
operands:
• Markers MD, MW, MB
• Analog output QA01
Value range for inputs and outputs
Example:
Displaying the parameter set in the PARAMETERS
menu
• + Access enabled
• – Access disabled
Value range Resolution/unit
>I1 Setpoint of PID controller –32768 to +32767
>I2 Actual value of PID controller –32768 to +32767
>KP Proportional gain K
p
0 to 65535 in -- /%
>TN Reset time T
n
0 to 65535 in 100/ms
>TV Rate time T
v
0 to 65535 in 100/ms
>TC Scan time 0 to 65535 in 100/ms
>MV Manual manipulated variable –4096 to +4095
QV> Manipulated variable 0 to 4095 (unipolar)
–4096 to +4095 (bipolar)
Value at input Value processed in
the function block.
>KP Proportional gain K
p
1500 15
>TN Reset time T
n
250 25 s
>TV Rate time T
v
200 20 s
>TC Scan time 500 50 s
>MV Manual manipulated variable 500 500
