ABB CL Series User Manual

Function blocks
217
1SVC 440 795 M1100
Time
00:00 to 23:59
Displaying the parameter set in the PARAMETERS
menu
• + Access enabled
• – Access disabled
Contacts
HW01Q1 to HW32Q1
Memory requirement of the 7-day time switch
The 7-day time switch function block requires 68 bytes of
memory plus 4 bytes per channel used.
Function of the 7-day time switch function block
The switching points are defined according to the
parameters entered.
MO to FR: On the weekdays Mo, Tu, We, Th, Fr
ON 10:00, OFF 18:00: On and off switching times for the
individual days of the week.
MO: Every Monday
ON 10:00: Switch on time
SA: Every Saturday
OFF 18:00: Switch off time
Switching on working days
Time switch HW01 switches on Monday to Friday between
6:30 and 9:30 and between 17:00 and 22:30.
HW01 B +
>DY1 MO
>DY2 FR
>ON 17:00
>OFF 22:30
HW01 A +
>DY1 MO
>DY2 FR
>ON 06:30
>OFF 09:30

ABB CL Series Specifications

General

Manufacturer	ABB
Rated Control Supply Voltage (Us)	24 V DC
Mounting	DIN Rail
Category	Relays
Contact Configuration	SPDT
Coil Voltage	24 V DC
Operating Temperature	-40°C to +70°C
Electrical Life	100 Thousand Cycles
Output	Relay
