ABB CL Series User Manual

Wiring with the display system
226
1SVC 440 795 M1100
Value range for inputs and outputs
Displaying the parameter set in the PARAMETERS
menu
• + Access enabled
• – Access disabled
Coil
VC01EN to VC32EN, function block enable
Memory requirement of the LS function block
The LS function block requires 64 bytes of memory plus
4 bytes per constant on the function block input.
Function of the function block
Value range
>I1 Input value of the function block –2147483648 to +2147483647
>X1 Lower value of source range
>X2 Lower value of target range
>Y1 Upper value of source range
>Y2 Upper value of target range
QV> Output value
h
The scaling function block must be enabled so that it can
work. Coil LS…EN is active. If coil LS…EN is not active,
the entire function block is deactivated and reset. The
output value is set to zero.

ABB CL Series Specifications

General

Manufacturer	ABB
Rated Control Supply Voltage (Us)	24 V DC
Mounting	DIN Rail
Category	Relays
Contact Configuration	SPDT
Coil Voltage	24 V DC
Operating Temperature	-40°C to +70°C
Electrical Life	100 Thousand Cycles
Output	Relay
