Wiring with the display system
248
1SVC 440 795 M1100
Parameter display and parameter set for timing relay:
The parameter display for a timing relay is used to modify the
switching function, time base or setpoint times and enable
the parameter display.
Timing relay modes
T 02 X M:S +
>I1
>I2
QV>
T 02 Timing relay function block number 02
X On-delay mode
M:S Time range Minute: Seconds
+ Appears in the parameter display
>I1 Time setpoint 1
>I2 Time setpoint 2 (with timing relay with 2 setpoints)
QV> Timed-out actual time in RUN mode
Parameter Switch function
X Switch with on-delay
?X Switch with on-delay and random time range
â Switch with off-delay
?â Switch with off-delay and random time range
Xâ On- and off-delayed
# Off-delayed with random time range, setpoint retriggerable
?# Off-delayed with random time range, retriggerable
?Xâ On- and off-delayed switching with random time, 2 time setpoints
ü Single-pulse switching
Ü Switch with flashing, synchronous, 2 time setpoint values
Ü Switch with flashing, asynchronous, 2 time setpoint values
