ABB CL Series User Manual

Visualization with the
display system
294
1SVC 440 795 M1100
Table 14: Numerical value – Analog value output
Figure: 161: Extended analog value output
Numerical
value 1:
Display of the analog value (0 to 1019)
Numerical
value 2:
Display of the analog value with the scaling
range 0 to 10, two decimal places, unit of
measure “V” (Volt), Always display sign: yes,
Display change – detection via internal limit
value comparison, numerical display flashing.
Numerical
value 3:
Display of the analog value with the scaling
range -5 to +5, two decimal places, unit of
measure “V” (Volt), Always display sign: no,
Display change – detection via internal limit
value comparison, numerical display inverted.
Analog input I3
Scale value 0
Flashing +0.00V
Inverted -5.00V

ABB CL Series Specifications

General

Manufacturer	ABB
Rated Control Supply Voltage (Us)	24 V DC
Mounting	DIN Rail
Category	Relays
Contact Configuration	SPDT
Coil Voltage	24 V DC
Operating Temperature	-40°C to +70°C
Electrical Life	100 Thousand Cycles
Output	Relay
