ABB CL Series User Manual

Screen overview
295
1SVC 440 795 M1100
Screen 5:
Screen 5 shows an example of the output of analog values
(here IA3) on the display with the possibility of making them
invisible via I1 and I2. The settings for this were defined on
the Visibility tab. The screen shows two numerical values
that output the analog value in different formats. These
values are associated via analog input IA3 which provides a
value as variable type Word for further processing.
Table 15: Numerical value – Analog value output with invisible
display switch
Figure: 162: Invisible display switch
Numerical
value 1:
Display of the analog value with the scaling
range 0 to 10, two decimal places, unit of
measure “V” (Volt), Switch numerical value
invisible via Boolean operand I1, N/O contact
bit logic (Visibility tab)
Numerical
value 2:
Display of the analog value with the scaling
range –5 to +5, two decimal places, unit of
measure “V” (Volt), Switch numerical value
invisible via Boolean operand I2, N/O contact
bit logic (Visibility tab)
Invisibility
via I1
via I2 1.29V

ABB CL Series Specifications

General

Manufacturer	ABB
Rated Control Supply Voltage (Us)	24 V DC
Mounting	DIN Rail
Category	Relays
Contact Configuration	SPDT
Coil Voltage	24 V DC
Operating Temperature	-40°C to +70°C
Electrical Life	100 Thousand Cycles
Output	Relay
