Screen 6:
Screen 6 shows a simple example of the display change via
an external trigger. In this example, input I1 represents the
external trigger. This screen contains two numerical values.
These are associated with the QV output of the timing relay
T08 which is of variable type DWord. The timing relay is run
in a loop from 0 to 10 seconds.
Table 16: Numerical value – Analog value output with display
change by external trigger input
Figure: 163: External trigger
General
settings:
The value range from 0 to 11 000, unit of
measure: s (second), scaling range from 0 to
11, two decimal places, display change active,
detection via external trigger input.
Left numerical
value:
Display of timing relay value T08, I1 actuated:
The numerical value flashes since Display
change external trigger flashing via Boolean
operand I1 is set.
Right
numerical
value:
Display of timing relay value T08; I1 actuated:
The numerical value is displayed inverted since
Display change external trigger inverted via
Boolean operand I1 is set.
Display change (I1)
External trigger
3.37s 3.37s
