Screen overview
307
1SVC 440 795 M1100
Screen 1:
Screen 1 illustrates the activation of the message texts using
the associated variable. The output of two different texts in
one message text element is demonstrated. The first screen
contains four message text elements. These are triggered in
succession via the outputs Q1 to Q4 and appear in the
display.
The Message texts tab defines which message is to be
output for a particular state of the associated variable. In this
example, the message “no data” will be output when Q1 =
0, and “Information” will be output when Q1 = 1. All other
message texts elements have only one message text that is
displayed when the corresponding output Q… = 1.
Figure: 170: Text display via Boolean operands
Screen 2:
Screen 2 illustrates the activation of the message texts using
the associated variable. A message text is also displayed
enlarged. The screen contains two message text elements.
These are triggered in succession via the outputs Q1 to Q3
and appear in the display. The texts are only displayed if the
corresponding outputs are set to 1. No message text is
assigned to status 0.
Q1 = 0 Q1, Q2, Q3 = 1
no data Information
via
Boolean
operands!
Screen 2/Text 1
Text 2
To Next Page
