ABB CL Series User Manual

Screen overview
309
1SVC 440 795 M1100
Screen 5:
Screen 5 is essentially the same as screen 4 in which the
Invisibility function is replaced by a Flashing display change.
Input I2 = 1 (N/O contact bit logic) switches the message
text flashing.
Figure: 173: Message text flashing
Screen 6:
Screen 6 is essentially the same as screen 5 but with the
Inverted display change selected. Input I2 = 1 (N/O contact
bit logic) inverts the message text in this screen.
Figure: 174: Message text inverted
Screen 7:
Screen 7 is essentially the same as screen 6, but the inverted
display is controlled by a timer T07 (asynchronous pulse
generator). The text flashes in the display with different
pulse and pause times.
Figure: 175: Message text inverted flashing
I2 not actuated I2 actuated
I2 not actuated I2 actuated
Flashing
via I2!
Q2 ON
Flashing
via I2!
Q2 OFF
Inverse
via I2!
Q2 ON
Inverse
via I2!
Q2 OFF
Flashing
via timer
Q2 ON
Flashing
via timer
Q2 ON

ABB CL Series Specifications

General

Manufacturer	ABB
Rated Control Supply Voltage (Us)	24 V DC
Mounting	DIN Rail
Category	Relays
Contact Configuration	SPDT
Coil Voltage	24 V DC
Operating Temperature	-40°C to +70°C
Electrical Life	100 Thousand Cycles
Output	Relay
