Inside the display system
384
1SVC 440 795 M1100
X Switch to STOP mode.
X Select PROGRAM… from the main menu.
X Select the CARD… menu option.
The CARD… menu option will only appear if you have
inserted a functional memory module.
You can transfer a circuit diagram from the display system to
the module and from the module to the display system
memory or delete the content of the card.
X After transmission, remove the memory module and close
the cover.
Storing the circuit diagram on the memory module
X Select DEVICE-CARD.
X Confirm the prompt with OK to delete the contents of the
memory module and replace it with the display system
circuit diagram.
Press ESC to cancel.
Loading the circuit diagram from the module
X Select the CARD-> DEVICE menu option.
X Press OK to confirm the prompt if you want to delete the
display system memory and replace it with the module
content.
Press ESC to cancel.
h
If you are using a display without a keypad, you load the
programs with the CL-SOFT software. The automatic
loading function from the memory module when the power
supply is switched on is only supported on CL-LDC.L…
devices without a display and without a display module.
PROGRAM
DELETE PROG
CARD
DEVICE-CARD
CARD-DEVICE
DELETE CARD
h
If the operating voltage fails during communication with
the memory module, repeat the last step since the display
system may not have transferred or deleted all the data.
REPLACE ?
DEVICE-CARD
CARD-DEVICE
DELETE CARD
