Appendix
396
1SVC 440 795 M1100
Display module
CL-LDD.K, CL-LDD.XK
Power supply
Power supply with display base module
CL-LDC.L…
LCD display
Type Graphic/monochrome
Visible area W × H mm 62 × 33
Size of pixels mm 0.4 × 0.4
Number of pixels (W × H) 132 × 64
Spacing (pixel centre to pixel centre) mm 0.42
LCD backlight Yes
Backlight colour Yellow/green
The backlight can be used and programmed in
visualization applications
Yes
LEDs
Number of LEDs, can be used and programmed in
visualization applications
2
Operating buttons
Number 9
Can be used and programmed in visualization
applications
9
Mechanical lifespan Actuations Normally 1 × 10
6
Pushbutton illumination (LED)
Number 5
Colour Green
