ABB CL Series User Manual

Technical data
397
1SVC 440 795 M1100
Power supply
CL-LDC.L…
Rated voltage
Rated value V DC, (%) 24, (+20, –15)
Permissible range V DC 20.4 to 28.8
Residual ripple % F 5
Input current
At 24 V DC, CL-LDC.L…, typical mA 125
At 24 V DC, CL-LDC.L…, CL-LDD…, typical mA
250
At 24 V DC, CL-LDC.L…, CL-LDD…, CL-LDR…,
CL-LDT…, typical
mA 270
Voltage dips, IEC/EN 61131-2 ms
10
Heat dissipation
At 24 V DC, CL-LDC.L…, typical W 3
At 24 V DC, CL-LDC.L…, CL-LDD…, typical W 6
At 24 V DC, CL-LDC.L…, CL-LDD…, CL-LDR…,
CL-LDT…, typical
W 6.5

ABB CL Series Specifications

General

Manufacturer	ABB
Rated Control Supply Voltage (Us)	24 V DC
Mounting	DIN Rail
Category	Relays
Contact Configuration	SPDT
Coil Voltage	24 V DC
Operating Temperature	-40°C to +70°C
Electrical Life	100 Thousand Cycles
Output	Relay
