ABB CL Series User Manual

Technical data
399
1SVC 440 795 M1100
Inputs
CL-LDR…, CL-LDT…
Digital inputs
Number 12
Inputs usable as analog inputs (I7, I8, I11, I12) 4
Status display LCD status display,
if available
Electrical isolation
To supply voltage No
Between each other No
To the outputs Yes
To the PC interface, memory module, CL-NET and CL-LINK networks Yes
Rated voltage
Nominal value V DC 24
On signal 0
I1 to I6 and I9 to I10 V DC < 5
I7, I8, I11, I12 V DC < 8
On signal 1
I1 to I6 and I9 to I10 V DC > 15
I7, I8, I11, I12 V DC > 8
Input current on signal 1
I1 to I6, I9 to I10 at 24 V DC mA 3.3
I7, I8, I11, I12 at 24 V DC mA 2.2
Delay time from 0 to 1
Debounce ON ms 20
Debounce OFF, typical
I1 to I4 ms 0.025
I5, I6, I9, I10 ms 0.25
I7, I8, I11, I12 ms 0.15

ABB CL Series Specifications

General

Manufacturer	ABB
Rated Control Supply Voltage (Us)	24 V DC
Mounting	DIN Rail
Category	Relays
Contact Configuration	SPDT
Coil Voltage	24 V DC
Operating Temperature	-40°C to +70°C
Electrical Life	100 Thousand Cycles
Output	Relay
