ABB CL Series User Manual

Appendix
400
1SVC 440 795 M1100
Delay time from 1 to 0
Debounce ON ms 20
Debounce OFF, typical
I1 to I4 ms 0.025
I5, I6, I9, I10 ms 0.25
I7, I8, I11, I12 ms
0.15
Cable length (unshielded) m 100
High-speed counter inputs, I1 to I4
Number 4
Cable length (shielded) m 20
High-speed up and down counter
Counter frequency kHz <3
Pulse shape Square
Pulse pause ratio 1:1
Frequency counter
Counter frequency kHz < 3
Pulse shape Square
Pulse pause ratio 1:1
Incremental counter
Counter frequency kHz < 3
Pulse shape Square
Counter inputs I1and I2, I3 and I4 2
Signal offset 90°
Mark to space ratio 1:1
CL-LDR…, CL-LDT…

ABB CL Series Specifications

General

Manufacturer	ABB
Rated Control Supply Voltage (Us)	24 V DC
Mounting	DIN Rail
Category	Relays
Contact Configuration	SPDT
Coil Voltage	24 V DC
Operating Temperature	-40°C to +70°C
Electrical Life	100 Thousand Cycles
Output	Relay
